Wiluite

Ca19(Al,Mg)13(B,◻,Al)5(SiO4)10(Si2O7)4(O,OH)10
IMA status
  • Approved
IMA symbol
Wil
IMA approved
1997
Also known as
  • IMA1997-026
  • Viluite (of von Leonhard)

Where it forms, where it's found

Geological setting

metasomatized skarn

Type locality
Akhtaragda River mouth
  1. Vilyui River Basin
  2. Mirninsky District
  3. Sakha
  4. Russia

63.1061°, 112.2025°

9recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789106/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous
Transparency
Transparent · Translucent
Colour
Dark green
Streak
Colourless
Tenacity
brittle
Cleavage
Poor/Indistinct

Poor cleavage on (100).

Fracture
Irregular/Uneven
Density
3.36 g/cm³

Optical

Optical type
Uniaxial (+)
Refractive index
1.721 – 1.725
Surface relief
High
Principal indices
nω 1.721 · nε 1.725
UV response
none
Michel-Lévy diagramhighlighted lineδ = 0.0040
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]40 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation40 nm
Order1st order
XPL colour

Crystallography

Crystal system
Tetragonal
Space group
#186
Cell parameters
a = 15.716(1) Å · c = 11.704(1) Å
Z
2
Comment

Wiluite from Ariccia, Latium, Italy

Crystal structure

Synonyms

  • IMA1997-026
  • Viluite (of von Leonhard)

In other languages

French
Wiluite
German
IMA 1997-026 · Wiluit
Spanish
Wiluita
Italian
wiluite
Japanese
ウィルアイト
Chinese
硼符山石
Russian
вилуит

Classification

Strunz
10th ed.

9.BG.35

  • 9SilicatesClass
  • 9.BSorosilicatesDivision
  • 9.BGSorosilicates with mixed SiO4 and Si2O7 groups; cations in octahedral [6] and greater coordinationGroup
  • 9.BG.35WiluiteSpecies

Group, growth & confusion

Often grow together
2 minerals
Commonly confused with
3 minerals

Literature, links & citation

Citations
  1. 1797Klaproth, M. H. (1797) XXXI. 2. Untersuchung des Vesuvians, Vesuvian aus Sibirien. In Beiträge zur chemischen Kenntniss der Mineralkörper Vol. 2. Rottmann. p.33-38.
  2. 1994Groat, L.A., Hawthorne, F.C., Ercit, T.S. (1994) The incorporation of boron into the vesuvianite structure. The Canadian Mineralogist: 32: 505-523.
  3. 1996Grew, Edward S.; Anovitz, Lawrence M. - Eds. (1996) Boron - Mineralogy, Petrology and Geochemistry. Reviews in Mineralogy Vol. 33. Mineralogical Society of America p.862
  4. 1998Groat, L. A., Hawthorne, F. C., Erit, T. S., Grice, J. D. (1998) Wiluite, Ca19(Al,Mg,Fe,Ti)13(B,Al,◻)5Si18O68(O,OH)10, a new mineral species isostructural with vesuvianite, from the Sakha Republic, Russian Federation. The Canadian Mineralogist, 36 (5). 1301-1304
  5. 2005Bellatreccia, F., Camara, F., Ottolini, L., Della Ventura, G., Cibin, G., Mottana, A. (2005) Wiluite from Ariccia, Latium, Italy: Occurrence and crystal structure. The Canadian Mineralogist, 43 (5). 1457-1468 doi:10.2113/gscanmin.43.5.1457 DOI: 10.2113/gscanmin.43.5.1457
