Gordaite

NaZn4(SO4)(OH)6Cl · 6H2O
IMA status
  • Approved
IMA symbol
Gda
IMA approved
1996
Also known as
  • Gordaiet
  • IMA1996-006
  • UM1987-14-SO:ClHZn

Where it forms, where it's found

Geological setting

Oxidized vein material from a base metal mine.

Type locality
San Francisco Mine
  1. Caracoles
  2. Caracoles mining district
  3. Sierra Gorda
  4. Antofagasta Province
  5. Antofagasta
  6. Chile

-22.8786°, -69.3369°

26recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789102.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous · Pearly
Transparency
Transparent
Colour
Colourless · pale bluish · pale greenish
Streak
White
Tenacity
flexible
Cleavage
Perfect

Perfect on (001)

Density
2.627 g/cm³

Optical

Optical type
Uniaxial (-)
Refractive index
1.5382 – 1.5607
Surface relief
Moderate
Principal indices
nω 1.5607 · nε 1.5382
UV response
Not fluorescent
Michel-Lévy diagramhighlighted lineδ = 0.0225
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]225 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation225 nm
Order1st order
XPL colour

Crystallography

Crystal system
Trigonal
Space group
#79
Cell parameters
a = 8.413 Å · c = 13.095 Å
Z
2
Type-locality form

Colorless flakes associated with zincian paratacamite, and as interlocking anhedral plates up to 20 mm across.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
30ZnZincZinc465.380261.520
41.77%
8OOxygenOxygen1615.999255.984
40.88%
17ClChlorineChlorine135.45035.450
5.66%
16SSulfurSulfur132.06032.060
5.12%
11NaSodiumSodium122.99022.990
3.67%
1HHydrogenHydrogen181.00818.144
2.90%
Total626.148100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Gordaiet
  • IMA1996-006
  • UM1987-14-SO:ClHZn

In other languages

German
Gordait · IMA 1996-006
Italian
Gordaite

Classification

Strunz
10th ed.

7.DF.50

  • 7SulfatesClass
  • 7.DSulfates (selenates, etc.) with additional anions, with H2ODivision
  • 7.DFWith large and medium-sized cationsGroup
  • 7.DF.50GordaiteSpecies

Group, growth & confusion

Often grow together
1 mineral

Literature, links & citation

Citations
  1. 1987Brett, R., Evans, H. T., Jr., Gibson, E. K., Jr., Hedenquist, J. W., Wandless, M.-V. and Sommer, M. A. (1987): Mineralogical studies of sulfide samples and volatile concentrations of basalt glasses from the southern Juan de Fuca Ridge. Journal of Geophysical Research, 92(B11), 11373-11379. [as unnamed mineral (Na in formula not recognised)]
  2. 1997Adiwidjaja, G., Friese, K., Klaska, K.-H., Schlüter, J. (1997) The crystal structure of gordaite NaZn4(SO4)(OH)6Cl · 6H2O. Zeitschrift für Kristallographie - Crystalline Materials, 212 (10) 704-707 doi:10.1524/zkri.1997.212.10.704 DOI: 10.1524/zkri.1997.212.10.704
  3. 1997Zhu, Lin, Seff, Karl, Witzke, Thomas, Nasdala, Lutz (1997) Crystal structure of Zn4Na(OH)6SO4Cl·6H2O. Journal of Chemical Crystallography, 27 (5) 325-329 doi:10.1007/bf02575981DOI: 10.1007/bf02575981
  4. 1997Schlüter, Jochen, Klaska, Karl-Heinz, Friese, Karen, Adiwidjaja, Gunadi, Gebhard, Georg (1997) Gordaite, NaZn4(SO4)(OH)6Cl·6H2O, a new mineral from the San Francisco Mine, Antofagasta, Chile. Neues Jahrbuch für Mineralogie - Monatshefte, 1997 (4) 155-162 doi:10.1127/njmm/1997/1997/155DOI: 10.1127/njmm/1997/1997/155
  5. 1998Mandarino, Joseph A. (1998) Abstracts of New Mineral Descriptions. The Mineralogical Record, 29 (3) 233-237
