Guarinoite

Zn6(SO4)(OH)10 · 5H2O
IMA status
  • Approved
IMA symbol
Gua
Discovered
1993
IMA approved
1991
Also known as
  • Guarinoiet
  • IMA1991-005

Where it forms, where it's found

Geological setting

Secondary alteration mineral.

Type locality
Cap Garonne Mine
  1. Le Pradet
  2. Toulon
  3. Var
  4. Provence-Alpes-Côte d'Azur
  5. France

43.0814°, 6.0322°

4recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789101.5 – 2/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Very pale pink · bright to deep pink.
Streak
Light pink
Cleavage
Perfect

(001)

Fracture
Irregular/Uneven
Density
2.80 g/cm³

Optical

Optical type
Uniaxial (-)
Refractive index
1.544 – 1.584
Surface relief
Moderate
Principal indices
nω 1.584 · nε 1.544
Pleochroism
Strong

O = pink, E = light pink

UV response
Not fluorescent
Michel-Lévy diagramhighlighted lineδ = 0.0400
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]400 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation400 nm
Order1st order
XPL colour

Crystallography

Crystal system
Hexagonal
Cell parameters
a = 8.344(2) Å · c = 21.59(2) Å
Z
3
Morphology

Tabular (001)

Type-locality form

Aggregates of hexagonal crystals.

Comment

Space group P63, P63/m or P6322.

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
30ZnZincZinc665.380392.280
52.41%
8OOxygenOxygen1915.999303.981
40.61%
16SSulfurSulfur132.06032.060
4.28%
1HHydrogenHydrogen201.00820.160
2.70%
Total748.481100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Guarinoiet
  • IMA1991-005

In other languages

German
Guarinoit · IMA 1991-005
Italian
Guarinoite
Chinese
瓜里诺石

Classification

Strunz
10th ed.

7.DD.80

  • 7SulfatesClass
  • 7.DSulfates (selenates, etc.) with additional anions, with H2ODivision
  • 7.DDWith only medium-sized cations; sheets of edge-sharing octahedraGroup
  • 7.DD.80GuarinoiteSpecies
Dana
8th ed.

31.02.04.01

  • 31Hydrated Sulfates Containing Hydroxyl or HalogenClass
  • 31.02(AB)6(XO4)Zq·xH2OType
  • 31.02.04— unnamed intermediate level —Group
  • 31.02.04.01GuarinoiteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 1991Riviéra Scientifique (1991): 27-40.
  2. 1993Sarp, H. (1993) Guarinoite (Zn,Co,Ni)6(SO4)(OH,Cl)10·5H2O et thérèsemagnanite (Co,Zn,Ni)6(SO4)(OH,Cl)10·8H2O, deux nouveaux minéraux de la mine de Cap Garonne, Var, France. Archives des Sciences, Genève, 46 (1) 37-44
  3. 1997Mandarino, Joseph A. (1997) New Minerals 1990-1994. The Mineralogical Record Inc., Tuscon, Arizona. 220pp.
  4. 2005Favreau, G. (2005) Découverte de guarinoite dans l'Utah, Le Cahier des Micromonteurs: 4/2005: 30.
  5. 2005(2005) Guarinoite. Handbook of Mineralogy. Mineralogical Society of America
