Thérèsemagnanite

NaCo4(SO4)(OH)6Cl · 6H2O
IMA status
  • Approved
IMA symbol
Tmg
IMA approved
1991
Also known as
  • Cobaltogordaite
  • IMA1991-026
  • Thérèsemagnaniet
  • +1 more

Where it forms, where it's found

Type locality
Cap Garonne Mine
  1. Le Pradet
  2. Toulon
  3. Var
  4. Provence-Alpes-Côte d'Azur
  5. France

43.0814°, 6.0322°

4recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789101.5 – 2/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Pearly
Colour
Pink to light pink
Streak
Light pink
Cleavage
Perfect

(001)

Fracture
Irregular/Uneven
Density
2.52 g/cm³

Optical

Optical type
Uniaxial (-)
Refractive index
1.542 – 1.568
Surface relief
Moderate
Principal indices
nω 1.568 · nε 1.542
Pleochroism
Strong

0=pink, E=light pink to colorless.

UV response
None
Michel-Lévy diagramhighlighted lineδ = 0.0260
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]260 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation260 nm
Order1st order
XPL colour

Crystallography

Crystal system
Trigonal
Space group
#79
Cell parameters
a = 8.363(8) Å · c = 13.031(2) Å
Z
3
Type-locality form

Occurs as pink to light pink, thin platy crystals, making up radiating spherules to 0.2mm.

Comment

Cell data for neotype (Kasatkin et al., 2018).

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1615.999255.984
42.64%
27CoCobaltCobalt458.933235.732
39.27%
17ClChlorineChlorine135.45035.450
5.90%
16SSulfurSulfur132.06032.060
5.34%
11NaSodiumSodium122.99022.990
3.83%
1HHydrogenHydrogen181.00818.144
3.02%
Total600.360100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Cobaltogordaite
  • IMA1991-026
  • Thérèsemagnaniet
  • Theresmagnanite

In other languages

German
IMA 1991-026 · Thérèsemagnanit
Italian
thérèsemagnanite
Chinese
泰里斯马格南石

Classification

Strunz
10th ed.

7.DD.80

  • 7SulfatesClass
  • 7.DSulfates (selenates, etc.) with additional anions, with H2ODivision
  • 7.DDWith only medium-sized cations; sheets of edge-sharing octahedraGroup
  • 7.DD.80ThérèsemagnaniteSpecies
Dana
8th ed.

31.02.05.01

  • 31Hydrated Sulfates Containing Hydroxyl or HalogenClass
  • 31.02(AB)6(XO4)Zq·xH2OType
  • 31.02.05— unnamed intermediate level —Group
  • 31.02.05.01ThérèsemagnaniteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 1993Jambor, John L., Vanko, David A. (1993) New Mineral Names. American Mineralogist, 78 (11-12) 1314-1319
  2. 1993Sarp, H. (1993) Guarinoite (Zn,Co,Ni)6(SO4)(OH,Cl)10·5H2O et thérèsemagnanite (Co,Zn,Ni)6(SO4)(OH,Cl)10·8H2O, deux nouveaux minéraux de la mine de Cap Garonne, Var, France. Archives des Sciences, Genève, 46 (1) 37-44
  3. 2005(2005) Thérèsemagnanite. Handbook of Mineralogy. Mineralogical Society of America
  4. 2015Hålenius, U., Hatert, F., Pasero, M., Mills, S. J. (2015) New minerals and nomenclature modifications approved in 2015, CNMNC Newsletter No 27. Mineralogical Magazine, 79 (5). 1223-1230 doi:10.1180/minmag.2015.079.5.16DOI: 10.1180/minmag.2015.079.5.16
  5. 2017Hazen, Robert M., Hystad, Grethe, Golden, Joshua J., Hummer, Daniel R., Liu, Chao, Downs, Robert T., Morrison, Shaunna M., Ralph, Jolyon, Grew, Edward S. (2017) Cobalt mineral ecology. American Mineralogist, 102 (1) 108-116 doi:10.2138/am-2017-5798DOI: 10.2138/am-2017-5798
