Henrymeyerite

Ba(Ti7Fe2+)O16
IMA status
  • Approved
IMA symbol
Hmy
Also known as
  • Ba-Fe-priderite
  • Henrymeyeriet
  • IMA1999-016

Where it forms, where it's found

Geological setting

Occurs in a vein of tetra-ferriphlogopite – calcite – dolomite carbonatite.

mantle xenoliths

Type locality
Kovdor Zheleznyi Mine
  1. Kovdor Massif
  2. Kovdorsky District
  3. Murmansk Oblast
  4. Russia

67.5597°, 30.4258°

14recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105 – 6/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Adamantine
Transparency
Opaque
Colour
Greyish-brown · black
Streak
Reddish-brown
Tenacity
very brittle
Fracture
Splintery
Density
4.0 g/cm³

Optical

Optical colour
Greyish brown, grayish white
Bireflectance
Weak bireflectance in shades of brown
Tropism
Anisotropic
Reflectance R%
(13.0,14.2) 420, (12.2,13.4) 440, (12.0,13.0) 460, (11.9,12.8) 480, (11.8,12.7) 500, (11.8,12.6) 520, (11.6,12.6) 540, (11.5,12.6) 560, (11.4,12.7) 580, (11.4,12.9) 600, (11.4,13.2) 620, (11.4,13.5) 640, (11.3,13.8) 660, (11.3,14.1) 680, (11.2,14.4) 700, (11.2,14.5) 720
Reflected-light panel
11.7 %anisotropic · dual curve
Specimen sRGB 127, 88, 48
White reference100 % reflector under same lamp
R₁ R₂
Mode
Bireflectance
Weak bireflectance in shades of brown
Reflected colour
Greyish brown, grayish white

Crystallography

Crystal system
Tetragonal
Space group
#135
Cell parameters
a = 10.219(3) Å · c = 2.963(1) Å
Z
1
Morphology

Prismatic acicular, with forms (100), (110) and (101).

Type-locality form

Acicular crystals less than 0.2 mm in length.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
22TiTitaniumTitanium747.867335.069
42.73%
8OOxygenOxygen1615.999255.984
32.64%
56BaBariumBarium1137.327137.327
17.51%
26FeIronIron155.84555.845
7.12%
Total784.225100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Ba-Fe-priderite
  • Henrymeyeriet
  • IMA1999-016

In other languages

German
Henrymeyerit · IMA 1999-016
Italian
Henrymeyerite

Classification

Strunz
10th ed.

4.DK.05b

  • 4OxidesClass
  • 4.DMetal: Oxygen = 1:2 and similarDivision
  • 4.DKWith large (+- medium-sized) cations; tunnel structuresGroup
  • 4.DK.05bHenrymeyeriteSpecies

Group, growth & confusion

In the same group
4 members
Often grow together
5 minerals

Literature, links & citation

Citations
  1. 2000Mitchell, R. H., Yakovenchuk, V. N., Chakhmouradian, A. R., Burns, P. C., Pakhomovsky, Y. A. (2000) Henrymeyerite, a new hollandite-type Ba-Fe titanate from the Kovdor Complex, Russia. The Canadian Mineralogist, 38 (3) 617-626 doi:10.2113/gscanmin.38.3.617 DOI: 10.2113/gscanmin.38.3.617
  2. 2001Jambor, J.L. and Roberts, A.C. (2001) New mineral names. American Mineralogist: 86: 197-200.
  3. 2002Mandarino, Joseph A. (2002) New minerals. The Canadian Mineralogist, 40 (1) 247-254 doi:10.2113/gscanmin.40.1.247 DOI: 10.2113/gscanmin.40.1.247
  4. 2007Kogarko, L. N., Kurat, G., Ntaflos, T. (2007) Henrymeyerite in the metasomatized upper mantle of eastern Antarctica. The Canadian Mineralogist, 45 (3). 497-501 doi:10.2113/gscanmin.45.3.497DOI: 10.2113/gscanmin.45.3.497
  5. 2011(2011) Henrymeyerite. Handbook of Mineralogy. Mineralogical Society of America
