Hinsdalite

PbAl3(SO4)(PO4)(OH)6
IMA status
  • Approved
  • Grandfathered
IMA symbol
Hda
Discovered
1911
Also known as
  • Hinsdaliet
  • Orpheite

Where it forms, where it's found

Geological setting

Vein cutting volcanic rocks

Type locality
Golden Fleece Mine
  1. Lake City
  2. Lake City Mining District
  3. Hinsdale County
  4. Colorado
  5. USA

37.9806°, -107.3031°

94recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789104.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous · Greasy
Transparency
Transparent · Translucent
Colour
Colourless · greenish · pearly white
Streak
White
Cleavage
Perfect

Perfect on the (001)

Fracture
Irregular/Uneven
Density
3.65 g/cm³

Optical

Optical type
Uniaxial (+)
Refractive index
1.671 – 1.689
Surface relief
High
Principal indices
nω 1.671 · nε 1.689
Notes

The optical anomalies common to members of the Beudantite Subgroup are very conspicuous. Six biaxial segments in which the planes of the optic axes are arranged radially to the core at about 60° to each other, may surround an uniaxial core.

Michel-Lévy diagramhighlighted lineδ = 0.0180
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]180 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation180 nm
Order1st order
XPL colour

Crystallography

Crystal system
Trigonal
Space group
#99
Cell parameters
a = 6.97 Å · c = 16.8 Å
Unit cell volume
710.88 ų
Z
3
Morphology

Crystals rhobohedra (1011), hexagonal plates, tabular on (0001), or pseudocubic with rough or dull faces. Massive or granular.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1415.999223.986
38.54%
82PbLeadLead1207.200207.200
35.65%
13AlAluminiumAluminium326.98280.946
13.93%
16SSulfurSulfur132.06032.060
5.51%
15PPhosphorusPhosphorus130.97430.974
5.33%
1HHydrogenHydrogen61.0086.048
1.04%
Total581.214100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Hinsdaliet
  • Orpheite

In other languages

German
Hinsdalit
Italian
Hinsdalite · Orpheite

Classification

Strunz
10th ed.

8.BL.05

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.BPhosphates, etc., with additional anions, without H2ODivision
  • 8.BLWith medium-sized and large cations, (OH, etc.):RO4 = 3:1Group
  • 8.BL.05HinsdaliteSpecies
Dana
8th ed.

43.04.01.05

  • 43Compound Phosphates, Etc.Class
  • 43.04Anhydrous Compound Phosphates, etc·, Containing Hydroxyl or HalogenType
  • 43.04.01Beudantite GroupGroup
  • 43.04.01.05HinsdaliteSpecies
CIM

22.3.17

  • 22Phosphates, Arsenates or Vanadates with other AnionsClass
  • 22.3Phosphates, arsenates or vanadates with sulphatesGroup
  • 22.3.17HinsdaliteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 1911Larsen, E.S.; Schaller, W.T. (1911) Hinsdalite, a new mineral. Journal of the Washington Academy of Sciences, 1. p.25-26.
  2. 1911Larsen, E.S.; Schaller, W.T. (1911) Hinsdalite, a new mineral. American Journal Of Science, 32. p.251-255.
  3. 1911Larsen and Schaller (1911) Zeitschrift für Kristallographie, Mineralogie und Petrographie, Leipzig: 50: 106.
  4. 1912Larsen, E. S.; Schaller, W. T. (1912) Hinsdalit, ein neues Mineral. Zeitschrift für Kristallographie, 50 (1-6). 101-105 doi:10.1524/zkri.1912.50.1.101DOI: 10.1524/zkri.1912.50.1.101
  5. 1934Larsen, E.S.; Berman, H. (1934) The microscopic determination of the nonopaque minerals. Bulletin of the US Geological Survey Vol. 848. US Geological Survey p.1-266. doi:10.3133/b848 DOI: 10.3133/b848
