Weilerite

BaAl3(SO4)(AsO4)(OH)6
IMA status
  • Approved
IMA symbol
Wlr
IMA approved
1987
Also known as
  • Weileriet

Where it forms, where it's found

Type locality
Michael Mine
  1. Weiler
  2. Seelbach
  3. Seelbach
  4. Ortenaukreis
  5. Freiburg Region
  6. Baden-Württemberg
  7. Germany

48.3419°, 7.9700°

5recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Colour
White
Streak
White

Optical

Optical type
Uniaxial

Crystallography

Crystal system
Hexagonal
Cell parameters
a = 7.05 Å · c = 15.16 Å
Z
3
Type-locality form

Earthy crust; idiomorphic crystals less than 10 microns.

Comment

Point group n.d.; space group n.d.

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1415.999223.986
40.34%
56BaBariumBarium1137.327137.327
24.73%
13AlAluminiumAluminium326.98280.946
14.58%
33AsArsenicArsenic174.92274.922
13.49%
16SSulfurSulfur132.06032.060
5.77%
1HHydrogenHydrogen61.0086.048
1.09%
Total555.289100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Weileriet

In other languages

German
Weilerit
Italian
weilerite

Classification

Strunz
10th ed.

8.BL.05

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.BPhosphates, etc., with additional anions, without H2ODivision
  • 8.BLWith medium-sized and large cations, (OH, etc.):RO4 = 3:1Group
  • 8.BL.05WeileriteSpecies
CIM

22.3.14

  • 22Phosphates, Arsenates or Vanadates with other AnionsClass
  • 22.3Phosphates, arsenates or vanadates with sulphatesGroup
  • 22.3.14WeileriteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 1961Walenta, K., Wimmenauer, W. (1961) Der Mineralbestand des Michaelganges im Weiler bei Lahr (Schwarzwald). Jahreshefte des Geologischen Landesamts Baden-Württemberg: 4: 7-37 (in German).
  2. 1962Fleischer, Michael (1962) New Mineral Names. American Mineralogist, 47 (3-4) 414-420
  3. 1966Walenta, Kurt, Walenta, Kurt (1966) Beiträge zur Kenntnis seltener Arsenatmineralien unter besonderer Berücksichtigung von Vorkommen des Schwarzwaldes. 3. Folge (Schluß). [Rare arsenate minerals with special consideration of occurrences in the Black Forest. Part III (end)]. Tschermaks Mineralogische und Petrographische Mitteilungen, 11 (1). 121-164 doi:10.1007/bf01127708DOI: 10.1007/bf01127708
  4. 1967Fleischer, M. (1967) New Mineral Names. American Mineralogist, 52 (9-10) 1579-1589
  5. 1987Scott, Keith M. (1987) Solid solution in, and classification of, gossan-derived members of the alunite-jarosite family, northwest Queensland, Australia. American Mineralogist, 72 (1-2) 178-187
