Kemmlitzite

SrAl3(AsO4)(SO4)(OH)6
IMA status
  • Approved
IMA symbol
Kml
Discovered
1969
Also known as
  • Kemmlitziet

Where it forms, where it's found

Geological setting

Kaolinized quartz porphyry.

Type locality
Kemmlitz
  1. Mügeln
  2. Nordsachsen
  3. Saxony
  4. Germany

51.2253°, 12.9910°

8recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789105.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Light grayish-brown · colorless · brownish (zonal)
Cleavage
Poor/Indistinct

Poor on (0001)

Density
3.63 g/cm³

Optical

Optical type
Uniaxial (+)
Refractive index
1.701 – 1.707
Surface relief
High
Principal indices
nω 1.701 · nε 1.707
Michel-Lévy diagramhighlighted lineδ = 0.0060
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]60 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation60 nm
Order1st order
XPL colour

Crystallography

Crystal system
Trigonal
Space group
R-3m
Cell parameters
a = 7.072(1) Å · c = 16.51(1) Å
Z
3
Type-locality form

Pseudo-cubic rhombohedral crystals with average rhombohedron edge 0.1-0.15 mm.

Comment

Space Group: by analogy to beudantite

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1415.999223.986
44.30%
38SrStrontiumStrontium187.62087.620
17.33%
13AlAluminiumAluminium326.98280.946
16.01%
33AsArsenicArsenic174.92274.922
14.82%
16SSulfurSulfur132.06032.060
6.34%
1HHydrogenHydrogen61.0086.048
1.20%
Total505.582100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Kemmlitziet

In other languages

German
IMA 1967-021 · Kemmlitzit
Italian
Kemmlitzite

Classification

Strunz
10th ed.

8.BL.05

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.BPhosphates, etc., with additional anions, without H2ODivision
  • 8.BLWith medium-sized and large cations, (OH, etc.):RO4 = 3:1Group
  • 8.BL.05KemmlitziteSpecies
Dana
8th ed.

43.04.01.07

  • 43Compound Phosphates, Etc.Class
  • 43.04Anhydrous Compound Phosphates, etc·, Containing Hydroxyl or HalogenType
  • 43.04.01Beudantite GroupGroup
  • 43.04.01.07KemmlitziteSpecies
CIM

22.3.10

  • 22Phosphates, Arsenates or Vanadates with other AnionsClass
  • 22.3Phosphates, arsenates or vanadates with sulphatesGroup
  • 22.3.10KemmlitziteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 1969Hak, J., Johan, Z., Kvacek, M. and Liebscher, W. (1969) Kemmlitzite, a new mineral of the woodhouseite group. Neues Jahrbuch für Mineralogie, Monatshefte: 1969: 201-212.
  2. 1970Fleischer, Michael (1970) New Mineral Names. American Mineralogist, 55 (1-2) 317-323
  3. 1987Scott, Keith M. (1987) Solid solution in, and classification of, gossan-derived members of the alunite-jarosite family, northwest Queensland, Australia. American Mineralogist, 72 (1-2) 178-187
  4. 1999Jambor, John L. (1999) Nomenclature of the alunite supergroup. The Canadian Mineralogist, 37 (6). 1323-1341
  5. 2005(2005) Kemmlitzite. Handbook of Mineralogy. Mineralogical Society of America
