Howlite

Ca2SiB5O9(OH)5
IMA status
  • Approved
  • Grandfathered
IMA symbol
How
Discovered
1868
Also known as
  • Howelite
  • Khaulit
  • Khaulita
  • +5 more

Where it forms, where it's found

Geological setting

Gypsum and anhydrite deposit.

In borate deposits. The common associates include those at Piskanya deposit (studenitsite is not a common species)

Type locality
Black's quarry
  1. Windsor
  2. Hants Co.
  3. Nova Scotia
  4. Canada

44.9583°, -64.1417°

28recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789106.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
White · colorless · brown
Streak
White
Cleavage

Even and smooth in porcelaneous types.

Density
2.62 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 60 – 90° · 2V calc = 88°
Refractive index
1.583 – 1.6
Surface relief
Moderate
Principal indices
nα 1.583 – 1.586 · nβ 1.596 – 1.598 · nγ 1.6
Dispersion
none
Extinction
X = b; Z ∧ c ≃ 51°.
UV response
May fluoresce orange or bluish white with SW or LW.
Michel-Lévy diagramhighlighted lineδ = 0.0155
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]155 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation155 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
P21/c
Cell parameters
a = 12.820(3) Å · b = 9.351(1) Å · c = 8.608(2) Å
Cell angles
β = 104.84(2) °
Ratio a:b:c
1 : 0.729 : 0.671
Unit cell volume
997.5 ų
Z
4
Morphology

Flattened prismatic with pointed terminations. Elongated on [010] or [001]. Compact nodular masses, internally dense and structureless. Chalk-like, earthy, scaly, slaty structured.

Type-locality form

Nodules embedded in anhydrite or gypsum.

Comment

Cell data from Griffen (1988).

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1415.999223.986
57.24%
20CaCalciumCalcium240.07880.156
20.48%
5BBoronBoron510.81054.050
13.81%
14SiSiliconSilicon128.08528.085
7.18%
1HHydrogenHydrogen51.0085.040
1.29%
Total391.317100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Na
  • K

Synonyms

  • Howelite
  • Khaulit
  • Khaulita
  • Khaulite
  • Silicoborocalcit
  • Silicoborocalcita
  • Silicoborocalcite
  • Winkworthite

In other languages

French
Howlite
German
Howlith
Spanish
Howlita
Italian
howlite
Japanese
ハウライト
Chinese
羟硅硼钙石
Traditional Chinese
白紋石
Russian
Говлит

Classification

Strunz
10th ed.

6.CB.20

  • 6BoratesClass
  • 6.CTriboratesDivision
  • 6.CBIno-triboratesGroup
  • 6.CB.20HowliteSpecies
Dana
8th ed.

25.03.05.01

  • 25Anhydrous Borates Containing Hydroxyl or HalogenClass
  • 25.03TriboratesType
  • 25.03.05— unnamed intermediate level —Group
  • 25.03.05.01HowliteSpecies
CIM

17.5.12

  • 17Silicates Containing other AnionsClass
  • 17.5BorosilicatesGroup
  • 17.5.12HowliteSpecies

Group, growth & confusion

Often grow together
6 minerals

Literature, links & citation

Citations
  1. 1868Dana, James D., Brush, George Jarvis (1868) A System of Mineralogy (5th ed.). p.882
  2. 1868How, H. (1868) Contributions to the mineralogy of Nova Scotia. III. Borates and other minerals in anhydrite and gypsum. Silicoborocalcite, a new mineral. Philosophical Magazine 35, (4th Ser.): 32-41: 218.
  3. 1871How, H. (1871) Contributions to the Mineralogy of Nova Scotia. VI. Winkworthite, a New Mineralfrom the Gypsum of Hants County. Philosophical Magazine and Journal of Science: 41: 270. (as Winkworthite).
  4. 1887Penfield, S.L., Sperry, E.S. (1887) On the chemical composition of howlite, with a note on the Gooch method for the determination of boracic acid. American Journal of Science: 134: 220-223.
  5. 1903Giles, W. B. (1903) Bakerite (a new borosilicate of calcium) and howlite from California. Mineralogical Magazine and Journal of the Mineralogical Society, 13 (62) 353-355 doi:10.1180/minmag.1903.013.62.12 DOI: 10.1180/minmag.1903.013.62.12
