Humboldtine

Fe2+(C2O4) · 2H2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Hbd
Discovered
1821
Also known as
  • Eisen-Resin
  • Faserresin
  • Humboldtit
  • +4 more

Where it forms, where it's found

Geological setting

Coal deposits; granitic pegmatites and hydrothermal mineral deposits (rare).

Type locality
Korozluky magmatic rock occurrence (Kolosoruk magmatic rock occurrence
  1. Kolloseruk magmatic rock occurrence)
  2. Korozluky
  3. Most District
  4. Ústí nad Labem Region
  5. Czech Republic

50.4826°, 13.7247°

28recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789101.5 – 2/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Yellow to amber-yellow · lemon-yellow
Cleavage
Perfect

On (110),perfect; on (100) and (010), imperfect.

Density
2.28 g/cm³

Optical

Optical type
Biaxial (+)
Refractive index
1.494 – 1.692
Surface relief
Moderate
Principal indices
nα 1.494 · nβ 1.561 · nγ 1.692
Pleochroism
Visible

X = Very pale yellowish green Y = Pale greenish yellow Z = Intense yellow

Dispersion
weak
Notes

2V = Large.

Michel-Lévy diagramhighlighted lineδ = 0.1980
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]1980 nm4th order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation1980 nm
Order4th order
XPL colour

Crystallography

Crystal system
Monoclinic
Cell parameters
a = 12.011(11) Å · b = 5.557(5) Å · c = 9.920(9) Å
Cell angles
β = 128.53(3) °
Ratio a:b:c
1 : 0.463 : 0.826
Z
4
Morphology

Crystals small, rare, prismatic [001], or platy, exhibiting forms (100),(001),(110), and (101); commonly botryoidal incrusting masses with a fibrous to earthy internal structure; fine-granular to earthy and compact.

Comment

Space group C2/c. Reduced cell: 9.707, 5.556, 9.921 A, 104.5°

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen615.99995.994
53.36%
26FeIronIron155.84555.845
31.04%
6CCarbonCarbon212.01124.022
13.36%
1HHydrogenHydrogen41.0084.032
2.24%
Total179.893100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Eisen-Resin
  • Faserresin
  • Humboldtit
  • Humboldtite
  • Humboltite
  • Oxalite
  • Oxalsaures Eisen

In other languages

German
Humboldtin
Italian
Humboldtina · Humboldtine · Ossalite · Oxalite
Arabic
همبولدتين

Classification

Strunz
10th ed.

10.AB.05

  • 10Organic CompoundsClass
  • 10.ASalts of organic acidsDivision
  • 10.ABOxalatesGroup
  • 10.AB.05HumboldtineSpecies
Dana
8th ed.

50.01.03.01

  • 50Organic CompoundsClass
  • 50.01OxalatesType
  • 50.01.03Humboldtine GroupGroup
  • 50.01.03.01HumboldtineSpecies
CIM

31.1.7

  • 31Oxalates, Citrates, Mellitates and AcetatesClass
  • 31.1OxalatesGroup
  • 31.1.7HumboldtineSpecies

Group, growth & confusion

In the same group
4 members
Often grow together
4 minerals

Literature, links & citation

Citations
  1. 1820Breithaupt, A. (1820) Kurze Charakteristik des Mineral-System’s. 8vo, Freiberg: 75 (as Faserresin).
  2. 1821de Rivero, M. (1821) Note sur une combinaison de l'acide oxalique avec le fer trouvé à Kolowserux, près Belin en Bohéme. Annales de Chimie et de Physique: 18: 207-210. (as Humboldtine and Oxalsaures Eisen)
  3. 1822Breithaupt, A. (1822) Annalen der Physik, Halle, Leipzig: 70: 426 (as Eisen-Resin).
  4. 1823Breithaupt, August (1823) Vollständige Charakteristik des Mineral-Systems (1st ed.). Arnoldischen Buchhandlung.
  5. 1826Leonhard, K.C. (1826) Handbuch der Oryktognosie. Heidelberg. second edition: 789 (as Humboldtit).
