Johnwalkite

K(Mn2+,Fe3+)2(Nb,Ta)O2(PO4)2 · 2(H2O,OH)
IMA status
  • Approved
IMA symbol
Jwk
Discovered
1985
IMA approved
1985
Also known as
  • IMA1985-008
  • Johnwalkiet

Where it forms, where it's found

Geological setting

Pegmatite.

Type locality
Champion Mine
  1. Keystone
  2. Keystone Mining District
  3. Pennington County
  4. South Dakota
  5. USA

Physical

Hardness
123456789104/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Opaque
Colour
Very dark reddish brown
Streak
Medium greenish yellow
Tenacity
brittle
Cleavage
Distinct/Good

Good on (001) and (100); poor on (010)

Density
3.40 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 53° · 2V calc = 50°
Refractive index
1.748 – 1.84
Surface relief
High
Principal indices
nα 1.748 · nβ 1.763 · nγ 1.84
Pleochroism
Strong

X = blue-green; Y = yellow to pale brown; Z = brown.

Dispersion
r > v strong
Extinction
X = c; Y = a; Z = b.
Notes

Absorption: X >> Z >> Y.

Michel-Lévy diagramhighlighted lineδ = 0.0920
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]920 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation920 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Orthorhombic
Cell parameters
a = 7.516(4) Å · b = 10.023(8) Å · c = 6.502(4) Å
Ratio a:b:c
1 : 1.334 : 0.865
Z
1
Type-locality form

Prismatic, dark reddish-brown radially arranged crystals to 6 mm.

Comment

Space Group: [Pb21m] (by analogy to olmsteadite).

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1415.999223.986
27.10%
73TaTantalumTantalum1180.948180.948
21.89%
26FeIronIron255.845111.690
13.51%
25MnManganeseManganese254.938109.876
13.30%
41NbNiobiumNiobium192.90692.906
11.24%
15PPhosphorusPhosphorus230.97461.948
7.50%
19KPotassiumPotassium139.09839.098
4.73%
1HHydrogenHydrogen61.0086.048
0.73%
Total826.500100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1985-008
  • Johnwalkiet

In other languages

German
IMA 1985-008 · Johnwalkit
Italian
Johnwalkite
Chinese
磷铌锰钾石

Classification

Strunz
10th ed.

8.DJ.05

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.DPhosphates, etc. with additional anions, with H2ODivision
  • 8.DJWith large and medium-sized cations, (OH, etc.):RO4 = 1:1Group
  • 8.DJ.05JohnwalkiteSpecies
Dana
8th ed.

42.07.11.02

  • 42Hydrated Phosphates, Etc.containing Hydroxyl or HalogenClass
  • 42.07(AB)2(XO4)Zq·xH2OType
  • 42.07.11Olmsteadite GroupGroup
  • 42.07.11.02JohnwalkiteSpecies
CIM

22.5.14

  • 22Phosphates, Arsenates or Vanadates with other AnionsClass
  • 22.5Phosphates, arsenates or vanadates with chromate, molybdate, niobate or tantalateGroup
  • 22.5.14JohnwalkiteSpecies

Group, growth & confusion

Often grow together
6 minerals

Literature, links & citation

Citations
  1. 1986Dunn, P. J., Peacor, D. R., Sturman, D. B., Ramik, R. A., Roberts, W. L., Nelen, J. A. (1986) Johnwalkite, the manganese analog of olmsteadite, from South Dakota. Neues Jahrbuch für Mineralogie - Monatshefte, 1986. 115-120
  2. 1987Hawthorne, F.C., Bladh, K.W., Burke, E.A.J, Grew, E.S., Langley, R.H., Puciewicz, J., Roberts, A.C., Schedler, R.A., Shigley, J.E., Vanko, D.A. (1987) New mineral names. American Mineralogist: 72: 222-230.
  3. 2007(2007) Johnwalkite. Handbook of Mineralogy. Mineralogical Society of America
