Fairfieldite

Ca2Mn2+(PO4)2 · 2H2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Ffd
Discovered
1879
Also known as
  • Fairfieldiet
  • Leucomanganite

Where it forms, where it's found

Geological setting

Late stage phosphate mineralization in a granite pegmatite.

Late stage phosphate mineralization in granite pegmatite.

Type locality
Fillow Quarry
  1. Branchville
  2. Redding
  3. Fairfield County
  4. Connecticut
  5. USA

41.2678°, -73.4392°

73recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
White · greenish white · light amber · salmon-yellow · colourless in transmitted light.

May be slightly stained yellow

Streak
White
Tenacity
brittle
Cleavage
Perfect

On (001) perfect; on (010), good; on (110), distinct.

Fracture
Irregular/Uneven
Density
3.08 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 86° · 2V calc = 86 – 88°
Refractive index
1.633 – 1.66
Surface relief
Moderate
Principal indices
nα 1.633 – 1.640 · nβ 1.641 – 1.650 · nγ 1.652 – 1.660
Birefringence
0.019
Pleochroism
Non-pleochroic
Dispersion
r>v relatively weak
Extinction
X (120°,60°); Y (–102°,36°); Z (18°,69°) using (φ,ρ).
UV response
Not fluorescent in UV.
Michel-Lévy diagramhighlighted lineδ = 0.0190
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]190 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation190 nm
Order1st order
XPL colour

Crystallography

Crystal system
Triclinic
Space group
P-1
Cell parameters
a = 5.78 Å · b = 6.57 Å · c = 5.48 Å
Cell angles
α = 102.08 ° · β = 108.71 ° · γ = 90.09 °
Ratio a:b:c
1 : 1.137 : 0.948
Z
1
Morphology

Crystals prismatic to equant; frequently composite. Commonly in foliated to lamellar crystalline aggregates, superficially resembling gypsum at times. Curved, foliated or fibrous at times; radiating masses.

Type-locality form

Massive crystalline aggregates; rarely in distinct crystals. Foliated to lamellar, sometimes resembling selenite. Also occasionally in radiating masses consisting of curved foliated or fibrous aggregates, resembling stilbite.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1015.999159.990
44.31%
20CaCalciumCalcium240.07880.156
22.20%
15PPhosphorusPhosphorus230.97461.948
17.16%
25MnManganeseManganese154.93854.938
15.21%
1HHydrogenHydrogen41.0084.032
1.12%
Total361.064100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Fairfieldiet
  • Leucomanganite

In other languages

German
Fairfieldit
Spanish
fairfieldita
Italian
Fairfieldite

Classification

Strunz
10th ed.

8.CG.05

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.CPhosphates without additional anions, with H2ODivision
  • 8.CGWith large and medium-sized cations, RO4:H2O = 1:1Group
  • 8.CG.05FairfielditeSpecies
Dana
8th ed.

40.02.02.01

  • 40Hydrated Normal Phosphates, Arsenates and VanadatesClass
  • 40.02AB2(XO4)2·xH2OType
  • 40.02.02Fairfieldite Subgroup (Triclinic: P-1¯)Group
  • 40.02.02.01FairfielditeSpecies
CIM

19.12.38

  • 19PhosphatesClass
  • 19.12Phosphates of MnGroup
  • 19.12.38FairfielditeSpecies

Group, growth & confusion

In the same group
1 members

Literature, links & citation

Citations
  1. 1878Brush, G.J., Dana, E.S. (1878) On a new and remarkable mineral locality in Fairfield County, Connecticut; with a description of several new species occurring there. American Journal of Science and Arts, 16, 33-46 and 114-123 (123-123).
  2. 1879Brush, G.J., Dana, E.S. (1879) On the mineral locality in Fairfield County, Connecticut, with the description of two additional new species. Second Paper. American Journal of Science and Arts, 17, 359-368.
  3. 1879Sandberger (1879) Neues Jahrbuch für Mineralogie, Geologie und Paleontologie, Heidelberg, Stuttgart: 370.
  4. 1885Sandberger (1885) Neues Jahrbuch für Mineralogie, Geologie und Paleontologie, Heidelberg, Stuttgart: I: 185.
  5. 1890Brush, G.J., Dana, E.S., Wells, H.L. (1890) On the mineral locality at Branchville, Connecticut: Fifth paper. American Journal of Science, 39, 201-216 (212).
