Kochsándorite

CaAl2(CO3)2(OH)4 · H2O
IMA status
  • Approved
IMA symbol
Ksd
IMA approved
2004
Also known as
  • IMA2004-037
  • Kochsándoriet

Where it forms, where it's found

Geological setting

Coal mine.

Type locality
Coal Mine
  1. Mány
  2. Bicskei District
  3. Fejér County
  4. Hungary

47.5450°, 18.6794°

2recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789102 – 2.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Colourless

Larger aggregates are white to pale brown.

Streak
White
Tenacity
brittle
Cleavage
None Observed
Fracture
None observed
Density
2.486 g/cm³

Optical

Optical type
Biaxial (-)
Refractive index
1.597 – 1.603
Surface relief
Moderate
Principal indices
nα 1.597 · nγ 1.603
Pleochroism
Non-pleochroic
Dispersion
r < v, weak.
UV response
Pale yellow under both short and long wave UV.
Notes

2V could not be measured.

Michel-Lévy diagramhighlighted lineδ = 0.0060
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]60 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation60 nm
Order1st order
XPL colour

Crystallography

Crystal system
Orthorhombic
Space group
#71
Cell parameters
a = 15.564(6) Å · b = 5.591(4) Å · c = 9.112(4) Å
Ratio a:b:c
1 : 0.359 : 0.585
Unit cell volume
792.9 ų
Z
4
Morphology

Forms, in order of prominence: (100), (110), (001) and (010).

Twinning

None observed.

Type-locality form

Spherical aggregates of acicular crystals up to 0.5 mm long, forming strings in massive coal.

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1115.999175.989
58.64%
13AlAluminiumAluminium226.98253.964
17.98%
20CaCalciumCalcium140.07840.078
13.36%
6CCarbonCarbon212.01124.022
8.00%
1HHydrogenHydrogen61.0086.048
2.02%
Total300.101100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA2004-037
  • Kochsándoriet

In other languages

German
IMA 2004-037 · Kochsándorit
Italian
Kochsándorite

Classification

Strunz
10th ed.

5.DB.10

  • 5CarbonatesClass
  • 5.DCarbonates with additional anions, with H2ODivision
  • 5.DBWith large and medium-sized cationsGroup
  • 5.DB.10KochsándoriteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 2007Sajó, I. E., Szakáll, S. (2007) Kochsándorite, a new Ca–Al carbonate mineral from the Mány coal deposit, Hungary. The Canadian Mineralogist, 45 (3). 479-483 doi:10.2113/gscanmin.45.3.479DOI: 10.2113/gscanmin.45.3.479
  2. 2014(2014) Kochsándorite. Handbook of Mineralogy. Mineralogical Society of America
