Milarite

KCa2(Be2AlSi12)O30 · H2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Mil
Discovered
1870
Also known as
  • Milariet

Where it forms, where it's found

Geological setting

In alpine and low-temperature hydrothermal veins.

Type locality
Val Giuv
  1. Tujetsch
  2. Surselva Region
  3. Grisons
  4. Switzerland

46.6924°, 8.7016°

151recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789106/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Colorless · grayish · tan · pale green · yellowish green · yellow
Streak
White
Tenacity
brittle
Fracture
Irregular/Uneven · Conchoidal
Density
2.46 g/cm³

Optical

Optical type
Uniaxial (-)
Refractive index
1.529 – 1.551
Surface relief
Moderate
Principal indices
nω 1.532 – 1.551 · nε 1.529 – 1.548
Notes

Also anomalously biaxial, sectored, with a uniaxial core.

Michel-Lévy diagramhighlighted lineδ = 0.0030
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]30 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation30 nm
Order1st order
XPL colour

Crystallography

Crystal system
Hexagonal
Space group
#123
Cell parameters
a = 10.42 Å · c = 13.80 Å
Z
2
Morphology

Hexagonal prisms.

Comment

Unit-cell parameters variable: a = 10.340-10.410, c = 13.758-13.845 Å.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen3115.999495.969
49.63%
14SiSiliconSilicon1228.085337.020
33.73%
20CaCalciumCalcium240.07880.156
8.02%
19KPotassiumPotassium139.09839.098
3.91%
13AlAluminiumAluminium126.98226.982
2.70%
4BeBerylliumBeryllium29.01218.024
1.81%
1HHydrogenHydrogen21.0082.016
0.20%
Total999.265100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Na
  • Y

Synonyms

  • Milariet

In other languages

German
Milarit
Spanish
Milarita
Italian
Milarite
Japanese
ミラー石
Chinese
整柱石

Classification

Strunz
10th ed.

9.CM.05

  • 9SilicatesClass
  • 9.CCyclosilicatesDivision
  • 9.CM[Si6O18]12- 6-membered double rings (sechser-Doppelringe)Group
  • 9.CM.05MilariteSpecies
Dana
8th ed.

63.02.1a.12

  • 63Cyclosilicates Condensed RingsClass
  • 63.02Condensed Rings (Milarite - Osumilite group)Type
  • 63.02.1a— unnamed intermediate level —Group
  • 63.02.1a.12MilariteSpecies
CIM

16.6.5

  • 16Silicates Containing Aluminum and other MetalsClass
  • 16.6Aluminosilicates of BeGroup
  • 16.6.5MilariteSpecies

Group, growth & confusion

Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1870Kenngott, A. (1870) Mittheilungen an Professor G. Leonhard. Neues Jahrbuch für Mineralogie, Geologie und Paläontologie: 1870: 80-81.
  2. 1885Rinne, F. (1885) Ueber Milarit, Apophyllit und Rutil. Neues Jahrbuch für Geologie, Mineralogie und Palaontologie, 11, 1-24.
  3. 1927Rinne, F. (1927) Milarit und metamilarit. Centralblatt für Mineralogie A, 1-14.
  4. 1930Goßner, B., Mußgnug, F. (1930) Über Alstonit und Milarit. Centralblatt für Mineralogie, Geologie und Paläontologie: 1930: 220-238.
  5. 1931Palache, Charles (1931) On the presence of beryllium in milarite. American Mineralogist, 16 (10) 469-470
