Morelandite

Ca2Ba3(AsO4)3Cl
IMA status
  • Approved
IMA symbol
Mldt
IMA approved
1977
Also known as
  • IMA1977-035
  • Morelandiet

Where it forms, where it's found

Type locality
Jakobsberg Mine
  1. Jakobsberg ore field
  2. Nordmark mining district
  3. Filipstad
  4. Värmland County
  5. Sweden

59.8280°, 14.1072°

2recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789104.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Light yellow to grey
Streak
White
Cleavage
Poor/Indistinct

Extremely weak parallel to (001).

Density
5.33 g/cm³

Optical

Optical type
Uniaxial (+)
Refractive index
1.88 – 1.884
Surface relief
Very high
Principal indices
nω 1.88 · nε 1.884
UV response
None observed.
Michel-Lévy diagramhighlighted lineδ = 0.0040
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]40 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation40 nm
Order1st order
XPL colour

Crystallography

Crystal system
Hexagonal
Cell parameters
a = 10.169(2) Å · c = 7.315(2) Å
Z
2
Type-locality form

Irregular segregations, to 2.5 cm, in calcite.

Comment

Point Group: 6/m or 6.: Space Group: P63/m or P63.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
56BaBariumBarium3137.327411.981
43.63%
33AsArsenicArsenic374.922224.766
23.80%
8OOxygenOxygen1215.999191.988
20.33%
20CaCalciumCalcium240.07880.156
8.49%
17ClChlorineChlorine135.45035.450
3.75%
Total944.341100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1977-035
  • Morelandiet

In other languages

German
IMA 1977-035 · Morelandit
Italian
Morelandite

Classification

Strunz
10th ed.

8.BN.05

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.BPhosphates, etc., with additional anions, without H2ODivision
  • 8.BNWith only large cations, (OH, etc.):RO4 = 0.33:1Group
  • 8.BN.05MorelanditeSpecies
Dana
8th ed.

41.08.05.01

  • 41Anhydrous Phosphates, Etc.containing Hydroxyl or HalogenClass
  • 41.08A5(XO4)3ZqType
  • 41.08.05Morelandite GroupGroup
  • 41.08.05.01MorelanditeSpecies
CIM

22.2.8

  • 22Phosphates, Arsenates or Vanadates with other AnionsClass
  • 22.2Phosphates, arsenates or vanadates with chlorideGroup
  • 22.2.8MorelanditeSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 1978Dunn, P. J., Rouse, R. C. (1978) Morelandite, a new barium arsenate chloride member of the apatite group. The Canadian Mineralogist, 16 (4) 601-604
  2. 1980Fleischer, M.; Mandarino, J.A.; Pabst, A. (1980) New mineral names. American Mineralogist, 65 (1-2). 205-210
  3. 2005(2005) Morelandite. Handbook of Mineralogy. Mineralogical Society of America
  4. 2008Đordević, Tamara; Šutović, Sabina; Stojanović, Jovica; Karanović, Ljiljana (2008) Sr, Ba and Cd arsenates with the apatite-type structure. Acta Crystallographica Section C Crystal Structure Communications, 64 (9). i82-i86 doi:10.1107/s0108270108023457DOI: 10.1107/s0108270108023457
  5. 2008Bell, Anthony M. T.; Henderson, C. Michael B.; Wendlandt, Richard F.; Harrison, Wendy J. (2008) Rietveld refinement of Ba5(AsO4)3Cl from high-resolution synchrotron data. Acta Crystallographica Section E Structure Reports Online, 64 (9). i63-i64 doi:10.1107/s1600536808026901DOI: 10.1107/s1600536808026901
