Nabalamprophyllite

(BaNa)Ti2Na3Ti(Si2O7)2O2(OH)2
IMA status
  • Approved
IMA symbol
Nlmp
IMA approved
2001
Also known as
  • Nabalamprophylliet

Where it forms, where it's found

Geological setting

ultrabasic rocks

alkaline pegmatite

Type locality
Kovdor Phlogopite mine
  1. Kovdor Massif
  2. Kovdorsky District
  3. Murmansk Oblast
  4. Russia

67.5892°, 30.4592°

4recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
yellowish brown
Streak
white
Tenacity
brittle
Cleavage
Perfect

on (100)

Density
3.62 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 40°
Refractive index
1.75 – 1.799
Surface relief
High
Principal indices
nα 1.750 · nγ 1.799
Pleochroism
Weak

greenish brown

Dispersion
strong dispersion, r > v
UV response
none
Michel-Lévy diagramhighlighted lineδ = 0.0490
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]490 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation490 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
P2/m
Cell parameters
a = 19.741(5) Å · b = 7.105(4) Å · c = 5.408(2) Å
Cell angles
β = 96.67(1) °
Ratio a:b:c
1 : 0.360 : 0.274
Z
2
Morphology

(100), (010), (130)

Type-locality form

flat prismatic brown to bright yellow crystals up to 1 cm

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1815.999287.982
37.15%
22TiTitaniumTitanium347.867143.601
18.52%
56BaBariumBarium1137.327137.327
17.72%
14SiSiliconSilicon428.085112.340
14.49%
11NaSodiumSodium422.99091.960
11.86%
1HHydrogenHydrogen21.0082.016
0.26%
Total775.226100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Nabalamprophylliet

In other languages

French
nabalamprophyllite
German
IMA 2001-060 · Nabalamprophyllit
Italian
Nabalamprofillite · nabalamprophillite · nabalamprophyllite
Russian
Набалампрофиллит

Classification

Strunz
10th ed.

9.BE.25

  • 9SilicatesClass
  • 9.BSorosilicatesDivision
  • 9.BESi2O7 groups, with additional anions; cations in octahedral [6] and greater coordinationGroup
  • 9.BE.25NabalamprophylliteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 2004Chukanov, N.V., Moiseev, M.M., Pekov, I.V., Lazebnik, K.A., Rastvetaeva, R.K., Zakayina, N.V., Ferraris, G., Ivaldi, G. (2004) Nabalamprophyllite, Ba(Na,Ba){Na3Ti[Ti2O2Si4O14](OH,F)2}, a new layer titanosilicate of the lamprophyllite group from alkaline-ultrabasic massifs Inagli and Kovdor, Russia. Zapiski Vserossiyskogo Mineralogicheskogo Obshchestva: 133(1): 59-72 (in Russian).
  2. 2004Mandarino, Joseph A. (2004) New minerals. The Canadian Mineralogist, 42 (6) 1901-1927 doi:10.2113/gscanmin.42.6.1901 DOI: 10.2113/gscanmin.42.6.1901
  3. 2005Piilonen, P. C. (2005) New mineral names. American Mineralogist, 90 (7) 1227-1232 doi:10.2138/am.2005.445DOI: 10.2138/am.2005.445
  4. 2008Sokolova, E., Hawthorne, F. C. (2008) From structure topology to chemical composition. IV. Titanium silicates: the orthorhombic polytype of nabalamprophyllite from the Lovozero massif, Kola Peninsula, Russia. The Canadian Mineralogist, 46 (5) 1323-1331 doi:10.3749/canmin.46.5.1323 DOI: 10.3749/canmin.46.5.1323
  5. 2016Rastsvetaeva, Ramiza K., Chukanov, Nikita V., Aksenov, Sergey M. (2016) The crystal chemistry of lamprophyllite-related minerals: a review. European Journal of Mineralogy, 28 (5) 915-930 doi:10.1127/ejm/2016/0028-2560DOI: 10.1127/ejm/2016/0028-2560
