Ourayite

Ag3Pb4Bi5S13
IMA status
  • Approved
IMA symbol
Our
Discovered
1977
Also known as
  • IMA1976-007
  • Ourayiet

Where it forms, where it's found

Type locality
Old Lout Mine
  1. Poughkeepsie Gulch
  2. San Juan County
  3. Colorado
  4. USA

37.9533°, -107.6247°

26recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789102/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Opaque
Density
7.18 g/cm³

Optical

Pleochroism
Weak

Weak in oil

Optical colour
galena-white
Anisotropism
Distinct to strong, pale gray to bluish black
Tropism
Anisotropic

Crystallography

Crystal system
Orthorhombic
Cell parameters
a = 13.457(1) Å · b = 44.042(4) Å · c = 4.100(10) Å
Ratio a:b:c
1 : 3.273 : 0.305
Z
4
Morphology

irregular laths, to < 0.1 mm.

Comment

Point Group: 2/m 2/m 2/m or mm2. ; Space Group: Bbmm or Bb21m.

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
83BiBismuthBismuth5208.9801044.900
39.97%
82PbLeadLead4207.200828.800
31.71%
16SSulfurSulfur1332.060416.780
15.94%
47AgSilverSilver3107.868323.604
12.38%
Total2614.084100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Cu
  • Sb

Synonyms

  • IMA1976-007
  • Ourayiet

In other languages

German
IMA 1976-007 · Ourayit
Italian
Ourayite

Classification

Strunz
10th ed.

2.JB.40c

  • 2Sulfides and SulfosaltsClass
  • 2.JSulfosalts of PbS archetypeDivision
  • 2.JBGalena derivatives, with PbGroup
  • 2.JB.40cOurayiteSpecies
Dana
8th ed.

03.05.06.01

  • 03SulfosaltsClass
  • 03.052.5 < ø < 3Type
  • 03.05.06— unnamed intermediate level —Group
  • 03.05.06.01OurayiteSpecies
CIM

5.7.25

  • 5Sulphosalts - Sulpharsenites and Sulphobismuthites (those containing Sn, Ge,or V are in Section 6)Class
  • 5.7Sulpharsenites etc. of Pb and other metalsGroup
  • 5.7.25OurayiteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 1977Makovicky, E. and Karup-Møller, S. (1977): Chemistry and crystallography of the lillianite homologous series. II. Definition of new minerals eskimoite, vikingite, ourayite and treasurite. Redefinition of schirmerite and new data on the lillianite-gustavite solid-solution series. Neues Jahrbuch für Mineralogie, Abhandlungen: 131: 56-82.
  2. 1977Karup-Møller, Sven (1977) Mineralogy of some Ag-(Cu)-Pb-Bi sulphide associations. Bulletin of the Geological Society of Denmark, 26. 41-68 doi:10.37570/bgsd-1976-26-03DOI: 10.37570/bgsd-1976-26-03
  3. 1979Fleischer, Michael, Chao, George Y., Pabst, and Adolf (1979) New Mineral Names. American Mineralogist, 64 (1-2) 241-245
  4. 1984Makovicky, E., Karup-Møller, S. (1984) Ourayite from Ivigtut, Greenland. The Canadian Mineralogist: 22(4): 565-575. https://rruff.info/rruff_1.0/uploads/CM22_565.pdf
  5. 2005(2005) Ourayite. Handbook of Mineralogy. Mineralogical Society of America
