Quintinite

Mg4Al2(OH)12(CO3) · 3H2O
IMA status
  • Approved
IMA symbol
Qtn
IMA approved
1992
Also known as
  • Quintiniet

Where it forms, where it's found

Geological setting

Late-stage hydrothermal mineral in miarolitic cavities and in pegmatitic bodies within nepheline syenite (quintinite-3T). Vugs in dolomitic carbonatite (quintinite-2H).

Type locality
Jacupiranga mine
  1. Cajati
  2. São Paulo
  3. Brazil

-24.6983°, -48.1259°

10recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789102/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous
Transparency
Transparent
Colour
Yellow to colorless · orange-brown
Streak
White
Tenacity
brittle
Cleavage
Perfect

(0001)

Fracture
Irregular/Uneven
Density
2.14 g/cm³

Optical

Optical type
Uniaxial
Refractive index
1.533
Surface relief
Moderate
Principal indices
nω 1.533 · nε 1.533
UV response
Not fluorescent.
Michel-Lévy diagramhighlighted lineδ = 0.0000
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]0 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation0 nm
Order1st order
XPL colour

Crystallography

Crystal system
Hexagonal
Space group
P63 2 2
Cell parameters
a = 10.571 Å · c = 15.139 Å
Unit cell volume
1465 ų
Z
6
Morphology

As equant and prismatic crystals displaying the forms (0001) and an {hkil} trapezohedron with or without (1010). As hexagonal tabular crystals on (0001), commonly forming rosettes.

Twinning

None observed.

Type-locality form

Equant and prismatic crystals. Hexagonal tabular crystals on (0001), commonly forming rosettes.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1815.999287.982
61.36%
12MgMagnesiumMagnesium424.30597.220
20.71%
13AlAluminiumAluminium226.98253.964
11.50%
1HHydrogenHydrogen181.00818.144
3.87%
6CCarbonCarbon112.01112.011
2.56%
Total469.321100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Quintiniet

In other languages

French
quintinite
German
IMA 1992-028 · Quintinit
Spanish
Quintinita
Italian
Quintinite

Classification

Strunz
10th ed.

5.DA.40

  • 5CarbonatesClass
  • 5.DCarbonates with additional anions, with H2ODivision
  • 5.DAWith medium-sized cationsGroup
  • 5.DA.40QuintiniteSpecies
Dana
8th ed.

16b.07.16.03

  • 16bHydrated Carbonates Containing Hydroxyl or HalogenClass
  • 16b.07MiscellaneousType
  • 16b.07.16— unnamed intermediate level —Group
  • 16b.07.16.03QuintiniteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 1997Chao, G. Y., Gault, R. A. (1997) Quintinite-2H, quintinite-3T, charmarite-2H, charmarite-3T and caresite-3T, a new group of carbonate minerals related to the hydrotalcite-manasseite group. The Canadian Mineralogist, 35 (6) 1541-1549
  2. 2007Frost, Ray L., Dickfos, Marilla (2007) Hydrated double carbonates – A Raman and infrared spectroscopic study. Polyhedron, 26 (15). 4503-4508 doi:10.1016/j.poly.2007.06.003DOI: 10.1016/j.poly.2007.06.003
  3. 2010Krivovichev, S. V., Yakovenchuk, V. N., Zhitova, E. S., Zolotarev, A. A., Pakhomovsky, Y. A., Ivanyuk, G. Yu. (2010) Crystal chemistry of natural layered double hydroxides. I. Quintinite-2H-3c from the Kovdor alkaline massif, Kola peninsula, Russia. Mineralogical Magazine, 74 (5) 821-832 doi:10.1180/minmag.2010.074.5.821DOI: 10.1180/minmag.2010.074.5.821
  4. 2010Krivovichev, S. V., Yakovenchuk, V. N., Zhitova, E. S., Zolotarev, A. A., Pakhomovsky, Y. A., Ivanyuk, G. Yu. (2010) Crystal chemistry of natural layered double hydroxides. 2. Quintinite-1M: first evidence of a monoclinic polytype in M2+-M3+ layered double hydroxides. Mineralogical Magazine, 74 (5) 833-840 doi:10.1180/minmag.2010.074.5.833DOI: 10.1180/minmag.2010.074.5.833
  5. 2010Zhitova, E. S., Yakovenchuk, V. N., Krivovichev, S. V., Zolotarev, A. A., Pakhomovsky, Y. A., Ivanyuk, G. Yu. (2010) Crystal chemistry of natural layered double hydroxides. 3. The crystal structure of Mg,Al-disordered quintinite-2H. Mineralogical Magazine, 74 (5) 841-848 doi:10.1180/minmag.2010.074.5.841DOI: 10.1180/minmag.2010.074.5.841
