Reddingite

Mn2+3(PO4)2 · 3H2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Rdd
Discovered
1878
Also known as
  • Reddingiet

Where it forms, where it's found

Geological setting

Granite pegmatite.

Type locality
Fillow Quarry
  1. Branchville
  2. Redding
  3. Fairfield County
  4. Connecticut
  5. USA

41.2678°, -73.4392°

34recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Colourless · pale pink or yellow · reddish brown to dark brown (altered) · colourless · faintly tinted pink in transmitted light
Streak
White
Tenacity
brittle
Cleavage
Poor/Indistinct

On (010), poor.

Fracture
Irregular/Uneven
Density
3 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 41 – 65° · 2V calc = 48 – 58°
Refractive index
1.643 – 1.685
Surface relief
High
Principal indices
nα 1.643 – 1.658 · nβ 1.648 – 1.664 · nγ 1.674 – 1.685
Pleochroism
Visible

Buckfield, Maine material: X = colourless; Y = pinkish brown; Z = pale yellow.

Dispersion
strong
Extinction
Parallel. X = a; Y = b; Z = c.
Michel-Lévy diagramhighlighted lineδ = 0.0290
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]290 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation290 nm
Order1st order
XPL colour

Crystallography

Crystal system
Orthorhombic
Space group
#70
Cell parameters
a = 9.49 Å · b = 10.08 Å · c = 8.7 Å
Ratio a:b:c
1 : 1.062 : 0.917
Morphology

Crystals pseudo-octahedral with large (111), or tabular (010). The crystals are frequently in parallel grouping. Massive, granular; coarsely fibrous. Forms include (111), (212), (221), (010), (223), (122).

Type-locality form

Minute orthorhombic octahedral crystals. Also massive and granular.

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1115.999175.989
43.05%
25MnManganeseManganese354.938164.814
40.32%
15PPhosphorusPhosphorus230.97461.948
15.15%
1HHydrogenHydrogen61.0086.048
1.48%
Total408.799100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Fe

Synonyms

  • Reddingiet

In other languages

German
Reddingit
Italian
Reddingite

Classification

Strunz
10th ed.

8.CC.05

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.CPhosphates without additional anions, with H2ODivision
  • 8.CCWith only medium-sized cations, RO4:H2O = 1:1.5Group
  • 8.CC.05ReddingiteSpecies
Dana
8th ed.

40.03.02.03

  • 40Hydrated Normal Phosphates, Arsenates and VanadatesClass
  • 40.03A3(XO4)2·xH2OType
  • 40.03.02Phosphoferrite GroupGroup
  • 40.03.02.03ReddingiteSpecies
CIM

19.12.20

  • 19PhosphatesClass
  • 19.12Phosphates of MnGroup
  • 19.12.20ReddingiteSpecies

Group, growth & confusion

In the same group
5 members
Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1878Brush, G.J., Dana, E.S. (1878) On a new and remarkable mineral locality in Fairfield County, Connecticut; with a description of several new species occurring there. First Paper. American Journal of Science and Arts, 116, 33-46; 114-123 (120).
  2. 1879Brush, G.J., Dana, E.S. (1879) On the Mineral Locality in Fairfield County, Connecticut, with the description of two additional new species. American Journal of Science: 17: 359-368 (365).
  3. 1890Brush, G.J., Dana, E.S., Wells, H.L. (1890) On the mineral locality at Branchville, Connecticut: Fifth paper. American Journal of Science, 39, 201-216 (211).
  4. 1921Larsen, Esper S. (1921) The microscopic determination of the nonopaque minerals. Bulletin 679. US Geological Survey doi:10.3133/b679 DOI: 10.3133/b679
  5. 1925Landes, Kenneth K. (1925) The paragenesis of the granite pegmatites of central Maine. American Mineralogist, 10 (11) 355-411
