Garyansellite

Mg2Fe3+(PO4)2(OH) · 2H2O
IMA status
  • Approved
IMA symbol
Gas
Discovered
1981
IMA approved
1981
Also known as
  • Garyanselliet
  • IMA1981-019

Where it forms, where it's found

Geological setting

fractures in a sedimentary iron formation; rare, low-temperature species

Type locality
Rapid Creek
  1. Dawson mining district
  2. Yukon
  3. Canada

68.5400°, -136.7996°

4recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
clove-brown

semitransparent

Streak
brown
Cleavage
Distinct/Good

(001)

Density
3.16 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 55° · 2V calc = 42°
Refractive index
1.733 – 1.761
Surface relief
High
Principal indices
nα 1.733 · nβ 1.757 · nγ 1.761
Pleochroism

reddish brown (X=Z), yellow (Y)

Dispersion
r < v
Notes

Orientation: X = b, Y = a, Z = c; absorption: Z = X > Y

Michel-Lévy diagramhighlighted lineδ = 0.0280
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]280 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation280 nm
Order1st order
XPL colour

Crystallography

Crystal system
Orthorhombic
Cell parameters
a = 9.45 Å · b = 9.89 Å · c = 8.19 Å
Ratio a:b:c
1 : 1.047 : 0.867
Type-locality form

Small colorless patches

Comment

Space group is Pbna; parameters from Zubkova et al. (2016): a=9.44738, b=9.85976, c=8.14154, V=758.38

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1115.999175.989
50.66%
15PPhosphorusPhosphorus230.97461.948
17.83%
26FeIronIron155.84555.845
16.07%
12MgMagnesiumMagnesium224.30548.610
13.99%
1HHydrogenHydrogen51.0085.040
1.45%
Total347.432100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Mn

Synonyms

  • Garyanselliet
  • IMA1981-019

In other languages

German
Garyansellit · IMA 1981-019
Italian
Garyansellite

Classification

Strunz
10th ed.

8.CC.05

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.CPhosphates without additional anions, with H2ODivision
  • 8.CCWith only medium-sized cations, RO4:H2O = 1:1.5Group
  • 8.CC.05GaryanselliteSpecies
Dana
8th ed.

40.03.02.05

  • 40Hydrated Normal Phosphates, Arsenates and VanadatesClass
  • 40.03A3(XO4)2·xH2OType
  • 40.03.02Phosphoferrite GroupGroup
  • 40.03.02.05GaryanselliteSpecies
CIM

19.14.12

  • 19PhosphatesClass
  • 19.14Phosphates of Fe and other metalsGroup
  • 19.14.12GaryanselliteSpecies

Group, growth & confusion

In the same group
5 members
Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1984Sturman, B. Darko, Dunn, Pete J. (1984) Garyansellite, a new mineral from Yukon Territory, Canada. American Mineralogist, 69 (1-2) 207-209
  2. 2005(2005) Garyansellite. Handbook of Mineralogy. Mineralogical Society of America
  3. 2016Anthony, John W., Bideaux, Richard A., Bladh, Kenneth W., Nichols, Monte C. - Eds. (2016) Handbook of Mineralogy. https://www.handbookofmineralogy.org/
  4. 2016Zubkova, N. V., Pekov, I. V., Kasatkin, A. V., Chukanov, N. V., Ksenofontov, D. A., Pushcharovsky, D. Yu. (2016) Crystal structure and refined formula of garyansellite Mg2Fe3+(PO4)2(OH) · 2H2O. Doklady Earth Sciences, 467 (1) 299-302 doi:10.1134/s1028334x16030235 DOI: 10.1134/s1028334x16030235
