Reedmergnerite

NaBSi3O8
IMA status
  • Approved
  • Grandfathered
IMA symbol
Rm
Discovered
1954
Also known as
  • Reedmergneriet

Where it forms, where it's found

Geological setting

Dolomitic shale

Type locality
Joseph Smith No. 1 well
  1. Duchesne County
  2. Utah
  3. USA
6recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789106 – 6.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Colourless to yellow-orange · salmon-orange
Cleavage
Perfect

(001)

Density
2.70 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 80° · 2V calc = 80°
Refractive index
1.554 – 1.573
Surface relief
Moderate
Principal indices
nα 1.554 · nβ 1.565 · nγ 1.573
Dispersion
none
Michel-Lévy diagramhighlighted lineδ = 0.0190
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]190 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation190 nm
Order1st order
XPL colour

Crystallography

Crystal system
Triclinic
Space group
#2
Cell parameters
a = 7.83 Å · b = 12.36 Å · c = 6.8 Å
Cell angles
α = 93.31 ° · β = 116.35 ° · γ = 92.06 °
Ratio a:b:c
1 : 1.579 : 0.868
Z
4
Type-locality form

As stubby prismatic to platy crystals, commonly wedge-shaped

Comment

Space Group: C_1

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen815.999127.992
52.02%
14SiSiliconSilicon328.08584.255
34.24%
11NaSodiumSodium122.99022.990
9.35%
5BBoronBoron110.81010.810
4.39%
Total246.047100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Ti
  • Al
  • Fe
  • Mg
  • Ca
  • Ba
  • K
  • F
  • H2O
  • P

Synonyms

  • Reedmergneriet

In other languages

German
Reedmergnerit
Italian
reedmergnerite
Russian
Ридмерджнерит

Classification

Strunz
10th ed.

9.FA.35

  • 9SilicatesClass
  • 9.FTektosilicates without zeolitic H2ODivision
  • 9.FATektosilicates without additional non-tetrahedral anionsGroup
  • 9.FA.35ReedmergneriteSpecies
Dana
8th ed.

76.01.04.01

  • 76Tectosilicates Al-si FrameworkClass
  • 76.01Al-Si Framework with Al-Si frameworksType
  • 76.01.04— unnamed intermediate level —Group
  • 76.01.04.01ReedmergneriteSpecies
CIM

17.5.2

  • 17Silicates Containing other AnionsClass
  • 17.5BorosilicatesGroup
  • 17.5.2ReedmergneriteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 1955Milton, C., Axelrod, J.M., Grimaldi, F.S. (1955) New minerals, reedmergnerite (Na2O·B2O3·6SiO2) and eitelite (Na2O·MgO·2CO2) associated with leucosphenite, shortite, searlesite, and crocidolite in the Green River formation, Utah. American Mineralogist: 40: 326-327.
  2. 1960Milton, C., Chao, E. C. T., Axelrod, J. M., Grimaldi, F. S. (1960) Reedmergnerite, NaBSi3O8, the boron analogue of albite, from the Green River Formation, Utah. American Mineralogist, 45 (1-2) 188-199
  3. 1961Fleischer, Michael (1961) New mineral names. American Mineralogist, 46 (3-4). 464-468
  4. 1992Fleet, Michael E. (1992) Tetrahedral-site occupancies in reedmergnerite and synthetic boron albite (NaBSi3O8) American Mineralogist, 77 (1-2) 76-84
  5. 1992Hackwell, T.P. and Angel, R.J. (1992) The comparative compressibility of reedmergnerite, danburite and their aluminum analogs. European Journal of Mineralogy: 4: 1221-1227.
