Slawsonite

Sr(Al2Si2O8)
IMA status
  • Approved
IMA symbol
Sws
Discovered
1977
Also known as
  • IMA1967-026
  • Slawsoniet

Where it forms, where it's found

Geological setting

Metamorphosed limestone.

Type locality
Martin Bridge formation
  1. Wallowa County
  2. Oregon
  3. USA
10recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105.5 – 6.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Colourless · gray
Streak
white
Cleavage
Distinct/Good

Good on (001), fair to good on (100).

Fracture
Sub-Conchoidal
Density
3.05 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 55 – 82° · 2V calc = 60 – 66°
Refractive index
1.57 – 1.586
Surface relief
Moderate
Principal indices
nα 1.570 – 1.573 · nβ 1.581 – 1.582 · nγ 1.585 – 1.586
Dispersion
r < v medium
Extinction
Y ∧ c = 5°-11°.
UV response
May fluoresce intense pinkish red-purple under SW UV
Michel-Lévy diagramhighlighted lineδ = 0.0140
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]140 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation140 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
P21/a
Cell parameters
a = 8.888(2) Å · b = 9.344(2) Å · c = 8.326(3) Å
Cell angles
β = 90.33(2) °
Ratio a:b:c
1 : 1.051 : 0.937
Z
4
Morphology

Tabular crystals, to 7 cm; in radial aggregates.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen815.999127.992
39.29%
38SrStrontiumStrontium187.62087.620
26.90%
14SiSiliconSilicon228.08556.170
17.24%
13AlAluminiumAluminium226.98253.964
16.57%
Total325.746100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Ti
  • Fe
  • Mg
  • Na
  • K
  • H2O

Synonyms

  • IMA1967-026
  • Slawsoniet

In other languages

German
IMA 1967-026 · Slawsonit
Italian
Slawsonite

Classification

Strunz
10th ed.

9.FA.50

  • 9SilicatesClass
  • 9.FTektosilicates without zeolitic H2ODivision
  • 9.FATektosilicates without additional non-tetrahedral anionsGroup
  • 9.FA.50SlawsoniteSpecies
Dana
8th ed.

76.01.05.02

  • 76Tectosilicates Al-si FrameworkClass
  • 76.01Al-Si Framework with Al-Si frameworksType
  • 76.01.05Paracelsian groupGroup
  • 76.01.05.02SlawsoniteSpecies
CIM

16.12.2

  • 16Silicates Containing Aluminum and other MetalsClass
  • 16.12Aluminosilicates of Sr, Ba and ZnGroup
  • 16.12.2SlawsoniteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 1977Griffen, Dana T., Ribbe, P. H., Gibbs, G. V. (1977) The structure of slawsonite, a strontium analog of paracelsian. American Mineralogist, 62 (1-2) 31-35
  2. 1979Franke, W., Ghobarkar, H., Heimann, R.B. (1979) The morphology of hydrothermally grown strontium paracelsian. Journal of Crystal Growth, 46 (4). 474-478 doi:10.1016/0022-0248(79)90032-0DOI: 10.1016/0022-0248(79)90032-0
  3. 1987Hawthorne, F.C., Bladh, K.W., Burke, E.A.J, Grew, E.S., Langley, R.H., Puciewicz, J., Roberts, A.C., Schedler, R.A., Shigley, J.E., Vanko, D.A. (1987) New mineral names. American Mineralogist: 72: 222-230.
  4. 1995Tagai, T., Hoshi, T., Suzuki, M., Kato, A., Matsubara, S. (1995) A new modification of slawsonite, SrAl2Si2O8: Its structure and phase transition. Zeitschrift für Kristallographie, 210 (10). doi:10.1524/zkri.1995.210.10.741 DOI: 10.1524/zkri.1995.210.10.741
  5. 2001(2001) Slawsonite. Handbook of Mineralogy. Mineralogical Society of America
