Tinzenite

Ca2Mn2+4Al4[B2Si8O30](OH)2
IMA status
  • Approved
IMA symbol
Tnz
Discovered
1923
Also known as
  • Tinzeniet
  • Tinzenito

Where it forms, where it's found

Type locality
Parsettens Alp
  1. Err valley
  2. Tinizong (Tinzen)
  3. Surses
  4. Albula Region
  5. Grisons
  6. Switzerland

46.5731°, 9.6844°

20recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789106.5 – 7/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous
Transparency
Transparent · Translucent
Colour
Lemon-yellow · orange · red
Tenacity
brittle
Cleavage
Distinct/Good

[(100) good; (001), (110), (011), poor] (by analogy to the axinite group

Fracture
Irregular/Uneven · Conchoidal
Density
3.355 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 80 – 84° · 2V calc = 62°
Refractive index
1.69 – 1.705
Surface relief
High
Principal indices
nα 1.690 · nβ 1.698 · nγ 1.705
Pleochroism
Weak

X = light brown; Y = violet; Z = light yellow or colorless in thick sections

Dispersion
weak to distinct
Michel-Lévy diagramhighlighted lineδ = 0.0150
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]150 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation150 nm
Order1st order
XPL colour

Crystallography

Crystal system
Triclinic
Space group
#2
Cell parameters
a = 7.14 Å · b = 9.11 Å · c = 8.90 Å
Cell angles
α = 102.9 ° · β = 98.1 ° · γ = 88 °
Ratio a:b:c
1 : 1.276 : 1.246
Z
2
Morphology

aggregates of prismatic crystals, to 5 mm; massive

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen3215.999511.968
43.83%
14SiSiliconSilicon828.085224.680
19.24%
25MnManganeseManganese454.938219.752
18.81%
13AlAluminiumAluminium426.982107.928
9.24%
20CaCalciumCalcium240.07880.156
6.86%
5BBoronBoron210.81021.620
1.85%
1HHydrogenHydrogen21.0082.016
0.17%
Total1168.120100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Ti
  • Mg
  • Ba
  • Na
  • K
  • H2O

Synonyms

  • Tinzeniet
  • Tinzenito

In other languages

German
Tinzenit
Spanish
Tinzenita
Italian
Tinzenite

Classification

Strunz
10th ed.

9.BD.20

  • 9SilicatesClass
  • 9.BSorosilicatesDivision
  • 9.BDSi2O7 groups, with additional anions; cations in tetrahedral [4] and greater coordinationGroup
  • 9.BD.20TinzeniteSpecies
Dana
8th ed.

56.02.02.04

  • 56Sorosilicates Si2o7 Groups, with Additional O, Oh, F and H2oClass
  • 56.02Si2O7 Groups and O, OH, F, and H2O with cations in [4] and/or >[4] coordinationType
  • 56.02.02Axinite groupGroup
  • 56.02.02.04TinzeniteSpecies
CIM

17.5.42

  • 17Silicates Containing other AnionsClass
  • 17.5BorosilicatesGroup
  • 17.5.42TinzeniteSpecies

Group, growth & confusion

In the same group
3 members
Often grow together
4 minerals

Literature, links & citation

Citations
  1. Philosophical Magazine: 42: 369-379.
  2. 1923Jakob, J. (1923) Vier Mangansilikate aus dem Val d'Err (Kt. Graubünden). Schweizerische Mineralogische und Petrographische Mitteilungen: 3: 227-237.
  3. 1926Jakob, J. (1926): Die Tinzenit-Varietäten aus dem Val d'Err, GR. Schweizerische Mineralogische und Petrographische Mitteilungen 6, 200-203.
  4. 1928Foshag, W.F. (1928) New mineral names. American Mineralogist: 13: 201-202.
  5. 1935Pelloux, A. (1935) Tinzenite e parsettensite della miniera di Cassagna (Liguria Orientale). Bollettino Societa Geologica Italiana: 53: 235-238.
