Trögerite

(H3O)(UO2)(AsO4) · 3H2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Tge
Discovered
1871
Also known as
  • Troegerite
  • Trögeriet

Where it forms, where it's found

Geological setting

Oxidised zone of a silver-nickel-arsenic-uranium deposit.

A secondary mineral of uranium mineral deposits.

Type locality
Walpurgis Flacher vein
  1. Weißer Hirsch Mine (shaft 3)
  2. Neustädtel
  3. Schneeberg
  4. Erzgebirgskreis
  5. Saxony
  6. Germany

50.5883°, 12.6389°

25recorded occurrences
Source · OpenStreetMap

Radioactivity

Physical

Hardness
123456789102 – 3/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Lemon-yellow · to deep yellow
Streak
White to pale yellow
Tenacity
brittle
Cleavage
Perfect

Perfect on (001), on (100) good; on (011) poor or in traces.

Fracture
Micaceous
Density
3.3 g/cm³

Optical

Optical type
Uniaxial (-) · 2V measured = 2°
Refractive index
1.58 – 1.63
Surface relief
Moderate
Principal indices
nα 1.585 · nβ 1.630 · nγ 1.630 · nω 1.580 · nε 1.620 – 1.624
Birefringence
0.045
Pleochroism
Visible

O = Y = Z = Lemon-yellow E = X = Nearly colourless

Dispersion
r > v
Extinction
Anomalously biaxial, X=c, Z ^ a = 13°, 2° = very small nearly zero
UV response
Lemon-yellow (UV).
Notes

May be biaxial -, probably anomalous, zoned due to differences in H2O content.

Michel-Lévy diagramhighlighted lineδ = 0.0450
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]450 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation450 nm
Order1st order
XPL colour

Crystallography

Crystal system
Tetragonal
Space group
P4/nmm
Cell parameters
a = 7.16 Å · c = 8.80 Å
Z
1
Morphology

Elongated thin tabular (001), often composite and uneven; nonpinacoidal forms asymmetrically developed, implying a Monoclinic symmetry; other faces small and striated horizontally. Found as crusts or aggregates of microscopic crystals, often found growing in parallel with zeunerite.

Twinning

None reported.

Epitaxy

Zeunerite crystals commonly occur overgrowing Trögerite in parallel position.

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
92UUraniumUranium1238.029238.029
49.38%
8OOxygenOxygen1015.999159.990
33.19%
33AsArsenicArsenic174.92274.922
15.55%
1HHydrogenHydrogen91.0089.072
1.88%
Total482.013100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Troegerite
  • Trögeriet

In other languages

German
Trögerit
Spanish
Troegerita · Trögerita
Italian
Trögerite

Classification

Strunz
10th ed.

8.EB.15

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.EUranyl phosphates and arsenatesDivision
  • 8.EBUO2:RO4 = 1:1Group
  • 8.EB.15TrögeriteSpecies
Dana
8th ed.

40.2a.20.01

  • 40Hydrated Normal Phosphates, Arsenates and VanadatesClass
  • 40.2aAB2(XO4)2·xH2O, containing (UO2)2+Type
  • 40.2a.20— unnamed intermediate level —Group
  • 40.2a.20.01TrögeriteSpecies
CIM

20.7.1

  • 20Arsenates (also arsenates with phosphate, but without other anions)Class
  • 20.7Arsenates of UGroup
  • 20.7.1TrögeriteSpecies

Group, growth & confusion

Often grow together
1 mineral

Literature, links & citation

Citations
  1. 1871Weisbach A. (1871), Vorläufige Mitteilung [Über Trögerit und Walpurgin].- Neues Jahrbuch für Mineralogie, Geologie und Paläontologie, 869-870.
  2. 1872Schrauf (1872) Mineralogische und petrographische Mitteilungen, Vienna: 185.
  3. 1873Weisbach A. (1873), Neue Uranerze von Neustädtel bei Schneeberg.- Jahrbuch für das Berg- und Hüttenwesen im Königreiche Sachsen, Abhandlungen, 119-121.
  4. 1873Winkler (1873) Journal für praktische Chemie, Leipzig: 7: 7.
  5. 1899Goldschmidt (1899) Zeitschrift für Kristallographie, Mineralogie und Petrographie, Leipzig: 31: 468.
