Uchucchacuaite

AgMnPb3Sb5S12
IMA status
  • Approved
IMA symbol
Uch
Discovered
1981
IMA approved
1981
Also known as
  • IMA1981-007
  • Uchucchacuaiet

Where it forms, where it's found

Type locality
Uchucchacua Mine
  1. Uchucchacua area
  2. Oyón District
  3. Oyón Province
  4. Lima
  5. Peru

-10.6231°, -76.6883°

6recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789103.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Metallic
Transparency
Opaque
Colour
Grey
Density
5.51 g/cm³

Optical

Tropism
Anisotropic
Reflectance R%
(36.2,44.3) 400, (36.3,44.2) 420, (35.8,44.2) 440, (35.2,43.8) 460, (35.0,43.9) 480, (34.7,43.7) 500, (34.5,43.4) 520, (34.1,43.3) 540, (33.8,43.0) 560, (33.5,42.6) 580, (33.2,42.4) 600, (33.0,42.0) 620, (32.7,41.8) 640, (32.3,41.2) 660, (31.8,40.6) 680, (31.2,39.9) 700
Reflected-light panel
34.0 %anisotropic · dual curve
Specimen sRGB 206, 146, 83
White reference100 % reflector under same lamp
R₁ R₂
Mode

Crystallography

Crystal system
Orthorhombic
Space group
#68
Cell parameters
a = 12.67 Å · b = 19.32 Å · c = 4.38 Å
Ratio a:b:c
1 : 1.525 : 0.346
Unit cell volume
1072.16 ų
Z
2
Twinning

Polysynthetic twinning along one direction.

Type-locality form

Anhedral grains and subhedral crystals to 200 µm.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
82PbLeadLead3207.200621.600
34.96%
51SbAntimonyAntimony5121.760608.800
34.24%
16SSulfurSulfur1232.060384.720
21.64%
47AgSilverSilver1107.868107.868
6.07%
25MnManganeseManganese154.93854.938
3.09%
Total1777.926100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Fe
  • Se

Synonyms

  • IMA1981-007
  • Uchucchacuaiet

In other languages

French
uchucchacuaïte
German
IMA 1981-007 · Uchucchacuait
Spanish
Uchucchacuaíta
Italian
Uchucchacuaite
Portuguese
Uchucchacuaita

Classification

Strunz
10th ed.

2.JB.40a

  • 2Sulfides and SulfosaltsClass
  • 2.JSulfosalts of PbS archetypeDivision
  • 2.JBGalena derivatives, with PbGroup
  • 2.JB.40aUchucchacuaiteSpecies
Dana
8th ed.

03.04.15.05

  • 03SulfosaltsClass
  • 03.04ø = 3Type
  • 03.04.15Lillianite Group (Orthorhombic, AmBnS6 where A=Pb, Ag, Mn and B=Sb, Bi)Group
  • 03.04.15.05UchucchacuaiteSpecies
CIM

5.8.2

  • 5Sulphosalts - Sulpharsenites and Sulphobismuthites (those containing Sn, Ge,or V are in Section 6)Class
  • 5.8Sulpharsenites etc. of Mn, Fe, Co and NiGroup
  • 5.8.2UchucchacuaiteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 1984Moëlo, Yves, Oudin, Elisabeth, Picot, Paul, Caye, René (1984) L'uchucchacuaïte, AgMnPb3Sb5S12, une nouvelle espèce minérale de la série de l'andorite. Bulletin de Minéralogie, 107 (5) 597-604 doi:10.3406/bulmi.1984.7803DOI: 10.3406/bulmi.1984.7803
  2. 1985Dunn, Pete J., Ferraiolo, James A., Fleischer, Michael, Gobel, Volker, Grice, Joel D., Langley, Richard H., Shigley, James E., Vanko, David A., Zilczer, Janet A. (1985) New mineral names. American Mineralogist, 70 (11-12) 1329-1335
  3. 1994Liu, H., Chang, L.L.Y., Knowles, C.R. (1994) The Mn isotype of andorite and uchucchacuaite. The Canadian Mineralogist: 32: 185-188.
  4. 2011Yang, H., Downs, R. T., Evans, S. H., Feinglos, M. N., Tait, K. T. (2011) Crystal structure of uchucchacuaite, AgMnPb3Sb5S12, and its relationship with ramdohrite and fizélyite. American Mineralogist, 96 (7) 1186-1189 doi:10.2138/am.2011.3809 DOI: 10.2138/am.2011.3809
  5. 2012NESPOLO, Massimo, OZAWA, Tohru, KAWASAKI, Yusuke, SUGIYAMA, Kazumasa (2012) Structural relations and pseudosymmetries in the andorite homologous series. Journal of Mineralogical and Petrological Sciences, 107 (6) 226-243 doi:10.2465/jmps.120730 DOI: 10.2465/jmps.120730
