Vuonnemite

Na6Na2Nb2Na3Ti(Si2O7)2(PO4)2O2(OF)
IMA status
  • Approved
IMA symbol
Vn
Discovered
1973
IMA approved
1973
Also known as
  • IMA1973-015
  • Vuonnemiet
  • Wuonnemit

Where it forms, where it's found

Geological setting

Albitized alkalic rocks

Type locality
Vuonnemiok River Valley
  1. Murmansk Oblast
  2. Russia

67.5819°, 34.1894°

13recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789102 – 3/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Light yellow to lemon-yellow · greenish yellow · light pink
Streak
white
Tenacity
brittle
Cleavage
Perfect

(001) "very perfect" plus two other perfect cleavages

Density
3.13 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 53 – 86° · 2V calc = 86°
Refractive index
1.636 – 1.681
Surface relief
High
Principal indices
nα 1.636 – 1.639 · nβ 1.651 – 1.656 · nγ 1.676 – 1.681
Dispersion
relatively weak
UV response
light to intense green or pale yellow under SW UV, yellow under LW UV, faint bluish green phosphorescence.
Notes

plane of optic axis (001), Y ∧ c = 4 deg

Michel-Lévy diagramhighlighted lineδ = 0.0410
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]410 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation410 nm
Order1st order
XPL colour

Crystallography

Crystal system
Triclinic
Cell parameters
a = 5.44(6) Å · b = 7.09(7) Å · c = 14.30(15) Å
Cell angles
α = 92.63 ° · β = 95.33 ° · γ = 90.51 °
Ratio a:b:c
1 : 1.303 : 2.629
Z
1
Type-locality form

Plates up to 1.8 x 1.5 x 0.15 cm

Comment

Point Group: _1 or 1; Space Group: P_1 or P1.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen2515.999399.975
37.04%
11NaSodiumSodium1122.990252.890
23.42%
41NbNiobiumNiobium292.906185.812
17.21%
14SiSiliconSilicon428.085112.340
10.40%
15PPhosphorusPhosphorus230.97461.948
5.74%
22TiTitaniumTitanium147.86747.867
4.43%
9FFluorineFluorine118.99818.998
1.76%
Total1079.830100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Al
  • Nb
  • Fe
  • Mn
  • Mg
  • Ca
  • K

Synonyms

  • IMA1973-015
  • Vuonnemiet
  • Wuonnemit

In other languages

German
IMA 1973-015 · Vuonnemit
Italian
vuonnemite
Russian
Вуоннемит

Classification

Strunz
10th ed.

9.BE.35

  • 9SilicatesClass
  • 9.BSorosilicatesDivision
  • 9.BESi2O7 groups, with additional anions; cations in octahedral [6] and greater coordinationGroup
  • 9.BE.35VuonnemiteSpecies
Dana
8th ed.

56.04.03.01

  • 56Sorosilicates Si2o7 Groups, with Additional O, Oh, F and H2oClass
  • 56.04Si2O7 Groups and O, OH, F, and H2O with [Si2O7] with other cation groupsType
  • 56.04.03— unnamed intermediate level —Group
  • 56.04.03.01VuonnemiteSpecies
CIM

17.6.11

  • 17Silicates Containing other AnionsClass
  • 17.6Silicates with phosphateGroup
  • 17.6.11VuonnemiteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 1973Bussen, I.V., Denisov, A.P., Zabavnikova, N.I., Kozyreva, L.V., Men'Shikov, Y.P., Lipatova, E.A. (1973) Vuonnemite, a new mineral. Zapiski Vserossijskogo Mineralogicheskogo Obshchestva: 102: 423-426.
  2. 1974Fleischer, Michael (1974) New mineral names. American Mineralogist, 59 (7-8). 873-875
  3. 1974Drozdov, Y.N., Batalieva, N.G., Voronkov, A.A., Kuz’min, E.A. (1974) The crystal structure of Na11Nb2TiSi4P2O25F. Soviet Physics - Doklady: 19: 258-260.
  4. 1983Rønsbo, J. G., Lenonardsen, E. S., Petersen, O. V., Johnsen, O. (1983) Second occurrence of vuonnemite: the Ilímaussaq alkaline intrusion, South Greenland. Neues Jahrbuch für Mineralogie - Monatshefte, 1983 (10) 451-460
  5. 1998Ercit, T. S., Cooper, M. A., Hawthorne, F. C. (1998) The crystal structure of vuonnemite, Na11Ti4+Nb2(Si2O7)2(PO4)2O3(F,OH), a phosphate-bearing sorosilicate of the lomonosovite group. The Canadian Mineralogist, 36 (5). 1311-1320
