Yoderite

(MgAl3)(MgAl)Al2O2(SiO4)4(OH)2
IMA status
  • Approved
IMA symbol
Yod
Discovered
1959
Also known as
  • Yoderiet

Where it forms, where it's found

Geological setting

Major phase in kyanite-quartz-talc schist ~10 kb water pressure, 800 °C.

Type locality
Mautia Hill
  1. Kongwa
  2. Kongwa District
  3. Dodoma Region
  4. Tanzania

-6.1368°, 36.4798°

2recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789106/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Deep purple to dark violet · green (rare)
Cleavage
Distinct/Good

(001)

Density
3.39 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 25 – 30° · 2V calc = 34 – 36°
Refractive index
1.689 – 1.715
Surface relief
High
Principal indices
nα 1.689 – 1.691 · nβ 1.691 – 1.693 · nγ 1.712 – 1.715
Pleochroism
Visible

Blue - prussian blue, indigo, olive green Green - Green, pale yellow, yellow Color - alpha, beta, gamma

Dispersion
weak to moderate
Michel-Lévy diagramhighlighted lineδ = 0.0235
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]235 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation235 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
#15
Cell parameters
a = 8.02 Å · b = 5.81 Å · c = 7.25 Å
Cell angles
β = 104.91 °
Ratio a:b:c
1 : 0.724 : 0.904
Z
1
Morphology

Anhedral grains, bladed or lathlike crystals to 12mm

Parting
[001] good (100) poor
Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen2015.999319.980
49.62%
13AlAluminiumAluminium626.982161.892
25.11%
14SiSiliconSilicon428.085112.340
17.42%
12MgMagnesiumMagnesium224.30548.610
7.54%
1HHydrogenHydrogen21.0082.016
0.31%
Total644.838100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Ti
  • Mn
  • H2O
  • P

Synonyms

  • Yoderiet

In other languages

German
Yoderit
Spanish
Yoderita
Italian
Yoderite
Russian
Йодерит

Classification

Strunz
10th ed.

9.AF.25

  • 9SilicatesClass
  • 9.ANesosilicatesDivision
  • 9.AFNesosilicates with additional anions; cations in [4], [5] and/or only [6] coordinationGroup
  • 9.AF.25YoderiteSpecies
Dana
8th ed.

52.02.2b.03

  • 52Nesosilicates Insular Sio4 Groups and O, Oh, F, H2oClass
  • 52.02Insular SiO4 Groups and O, OH, F, and H2O with cations in [4] and >[4] coordinationType
  • 52.02.2b— unnamed intermediate level —Group
  • 52.02.2b.03YoderiteSpecies
CIM

16.19.9

  • 16Silicates Containing Aluminum and other MetalsClass
  • 16.19Aluminosilicates of Fe and MgGroup
  • 16.19.9YoderiteSpecies

Group, growth & confusion

Often grow together
4 minerals

Literature, links & citation

Citations
  1. 1959McKie D, Radford A J (1959) Yoderite, a new hydrous magnesium iron alumino-silicate from Mautia Hill, Tanganyika. Mineralogical Magazine 32, 282-307.
  2. 1960Fleischer, M.; Chao, E.C.T. (1960) New mineral names. American Mineralogist, 45 (5-6). 753-756
  3. 1982Higgins, J.B., Ribbe, P.H., and Nakajima, Y. (1982) An ordering model for the commensurate antiphase structure of yoderite. American Mineralogist: 67: 76-84.
  4. 1991Fockenberg, T., Schreyer, W. (1991) Yoderite, a mineral with essential ferric iron: Its lack of occurrence in the system MgO-Al2O3-SiO2-H2O. American Mineralogist, 76 (5-6) 1052-1060
  5. 1993Fockenberg, T., Schreyer, W. (1993) Synthesis and properties of Mn-bearing yoderite and of Mn-bearing kornerupine as by-product. Mineralogy and Petrology, 48 (2) 115-128 doi:10.1007/bf01163091DOI: 10.1007/bf01163091
