Alumoåkermanite

(Ca,Na)2(Al,Mg,Fe2+)(Si2O7)
IMA status
  • Approved
IMA symbol
Aåk
IMA approved
2008
Also known as
  • Alumnoakermanite
  • Alumoåkermaniet
  • Alumoåkermanitt
  • +6 more

Where it forms, where it's found

Geological setting

Olivine-free melilite-nephelinitic ashes and lapilli-tuff.

Type locality
Ol Doinyo Lengai
  1. Ngorongoro District
  2. Arusha region
  3. Tanzania

-2.7616°, 35.9137°

18recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104.5 – 5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Light brown
Streak
White
Tenacity
brittle
Cleavage
None Observed
Fracture
Irregular/Uneven
Density
2.96 g/cm³

Optical

Optical type
Uniaxial (-)
Refractive index
1.625 – 1.635
Surface relief
Moderate
Principal indices
nω 1.635 · nε 1.625
Pleochroism
Non-pleochroic
Extinction
straight
UV response
none
Michel-Lévy diagramhighlighted lineδ = 0.0100
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]100 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation100 nm
Order1st order
XPL colour

Crystallography

Crystal system
Tetragonal
Space group
#146
Cell parameters
a = 7.766(4) Å · c = 5.0297(4) Å
Z
2
Parting
none
Type-locality form

Tabular phenocrysts (up to 1.5 mm) and microphenocrysts in a fine-grained groundmass.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen715.999111.993
27.90%
20CaCalciumCalcium240.07880.156
19.97%
14SiSiliconSilicon228.08556.170
13.99%
26FeIronIron155.84555.845
13.91%
11NaSodiumSodium222.99045.980
11.45%
13AlAluminiumAluminium126.98226.982
6.72%
12MgMagnesiumMagnesium124.30524.305
6.06%
Total401.431100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Alumnoakermanite
  • Alumoåkermaniet
  • Alumoåkermanitt
  • IMA2008-049
  • Natriummelilith
  • Natronmelilith
  • Soda melilite
  • Soda-Melilite
  • Soda-Melilith

In other languages

German
Alumoåkermanit · IMA 2008-049
Italian
alumoåkermanite

Classification

Strunz
10th ed.

9.BB.10

  • 9SilicatesClass
  • 9.BSorosilicatesDivision
  • 9.BBSi2O7 groups, without non-tetrahedral anions; cations in tetrahedral [4] and greater coordinationGroup
  • 9.BB.10AlumoåkermaniteSpecies
Dana
8th ed.

55.04.01.05

  • 55Sorosilicates Si2o7 Groups, Generally with No Additional AnionsClass
  • 55.04Si2O7 Groups, Generally with No Additional Anions with cations in [8] and lower coordinationType
  • 55.04.01Melilite groupGroup
  • 55.04.01.05AlumoåkermaniteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 1970Louisnathan, S. John (1970) The crystal structure of synthetic soda melilite, CaNaAlSi2O7. Zeitschrift für Kristallographie, 131 (1-6). 314-321 doi:10.1524/zkri.1970.131.1-6.314 DOI: 10.1524/zkri.1970.131.1-6.314
  2. 1981Fitton, J. G., Hughes, D. J. (1981) Strontian melilite in a nephelinite lava from Etinde, Cameroon. Mineralogical Magazine, 44 (335) 261-264 doi:10.1180/minmag.1981.044.335.03 DOI: 10.1180/minmag.1981.044.335.03
  3. 2001Bindi, Luca, Bonazzi, Paola, Fitton, J. Godfrey (2001) Crystal chemistry of strontian soda melilite from nephelinite lava of Mt. Etinde, Cameroon. European Journal of Mineralogy, 13 (1) 121-125 doi:10.1127/0935-1221/01/0013-0121DOI: 10.1127/0935-1221/01/0013-0121
  4. 2009Wiedenmann, D., Zaitsev, A. N., Britvin, S. N., Krivovichev, S. V., Keller, J. (2009) Alumoåkermanite, (Ca,Na)2(Al,Mg,Fe2+)(Si2O7), a new mineral from the active carbonatite-nephelinite-phonolite volcano Oldoinyo Lengai, northern Tanzania. Mineralogical Magazine, 73 (3) 373-384 doi:10.1180/minmag.2009.073.3.373 DOI: 10.1180/minmag.2009.073.3.373
  5. 2009Wiedenmann, D., Zaitsev, A. N., Britvin, S. N., Krivovichev, S. V., Keller, J. (2009) Errata: Alumoåkermanite, (Ca,Na)2(AI,Mg,Fe2+)(Si2O7), a new mineral from the active carbonatite-nephelinite-phonolite volcano Oldoinyo Lengai, northern Tanzania. Mineralogical Magazine, 73 (6) 1063 doi:10.1180/s0026461x00053834DOI: 10.1180/s0026461x00053834
