Anningite-(Ce)

(Ca0.5Ce4+0.5)(VO4)
IMA status
  • Approved
IMA symbol
Aig-Ce
Also known as
  • Anningiet-(Ce)
  • Anningitt-(Ce)
  • IMA2024-060

Where it forms, where it's found

Geological setting

within a phosphate coprolite from the sand-dominated sediments of the Gara Samani Formation, Algeria

Type locality
Gara Samani Formation
  1. Timimoun
  2. Timimoun District
  3. Timimoun Province
  4. Algeria

29.6919°, 1.9392°

1recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104 – 5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Colour
green
Streak
white
Cleavage
None Observed
Fracture
Irregular/Uneven · Conchoidal
Density
3.887 g/cm³

Crystallography

Crystal system
Tetragonal
Space group
I41/amd
Cell parameters
a = 7.1500(4) Å · c = 6.3343(7) Å
Z
2
Type-locality form

small (typically up to 100 μm in length) sheaf-like aggregates composed of crystals 30–40 μm in length and about 7 μm in diameter. forms small crystals (30-40 μm in length and about 6-8 μm in width) with a tetragonal columnar habit. The crystals typically occur in compact divergent or radial aggregates up to 100 μm in size

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
58CeCeriumCerium0.5140.11670.058
34.17%
8OOxygenOxygen415.99963.996
31.21%
23VVanadiumVanadium150.94250.942
24.85%
20CaCalciumCalcium0.540.07820.039
9.77%
Total205.035100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From Mindat formula

Synonyms

  • Anningiet-(Ce)
  • Anningitt-(Ce)
  • IMA2024-060

In other languages

German
Anningit-(Ce) · IMA 2024-060

Classification

Strunz
10th ed.

8.AD.35

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.APhosphates, etc. without additional anions, without H2ODivision
  • 8.ADWith only large cationsGroup
  • 8.AD.35Anningite-(Ce)Species

Group, growth & confusion

Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 2025Bosi, Ferdinando; Hatert, Frédéric; Pasero, Marco; Mills, Stuart J. (2025) IMA Commission on New Minerals, Nomenclature and Classification (CNMNC) – Newsletter 83. European Journal of Mineralogy, 37 (1). 75-78 doi:10.5194/ejm-37-75-2025 DOI: 10.5194/ejm-37-75-2025
  2. 2026Środek, Dorota; Juroszek, Rafał; Cametti, Georgia; Benyoucef, Madani; Bouchemla, Imad; Krzykawski, Tomasz; Salamon, Mariusz A. (2026) Anningite-(Ce), (Ca0.5Ce4+0.5)(VO4), a new mineral from phosphate coprolite of the Gara Samani Formation, Algeria. Mineralogical Magazine, 90 (1). 131-137 doi:10.1180/mgm.2025.10110DOI: 10.1180/mgm.2025.10110
