Pretulite

Sc(PO4)
IMA status
  • Approved
IMA symbol
Ptu
Discovered
1996
IMA approved
1996
Also known as
  • IMA1996-024
  • Pretuliet

Where it forms, where it's found

Geological setting

Lazulite-quartz vein in quartz-rich phyllite

Common accessory mineral in lazulite-quartz veins from Krieglach, Mürzzuschlag and also from southern Lower Austria; in metamorphosed and hydrothermaly altered oolitic ironstones from St Aubin-des-Châteaux, Loire-Atlantique, Pays de Loire, France.

Type locality
Höllkogel
  1. Alpl
  2. Freßnitzgraben
  3. Krieglach
  4. Bruck-Mürzzuschlag District
  5. Styria
  6. Austria

47.5155°, 15.6207°

13recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Adamantine
Transparency
Transparent · Translucent
Colour
Pale pink · pale orange · dark orange
Streak
White
Tenacity
brittle
Cleavage
Perfect

parallel to (100)

Fracture
Splintery
Density
3.71 g/cm³

Optical

Optical type
Uniaxial (+)
Refractive index
1.79 – 1.86
Surface relief
Very high
Principal indices
nω 1.790 · nε 1.86
UV response
Weak orange in SW
Michel-Lévy diagramhighlighted lineδ = 0.0700
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]700 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation700 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Tetragonal
Space group
I41/amd
Cell parameters
a = 6.589(1) Å · c = 5.806(1) Å
Z
4
Type-locality form

anhedral grains, to 200 µm.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen415.99963.996
45.73%
21ScScandiumScandium144.95644.956
32.13%
15PPhosphorusPhosphorus130.97430.974
22.14%
Total139.926100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1996-024
  • Pretuliet

In other languages

German
IMA 1996-024 · Pretulit
Italian
Pretulite

Classification

Strunz
10th ed.

8.AD.35

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.APhosphates, etc. without additional anions, without H2ODivision
  • 8.ADWith only large cationsGroup
  • 8.AD.35PretuliteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 1982Milligan, W.O., Mullica, D.F., Beall, G.W., Boatner, L.A. (1982) Structural investigations of YPO4, ScPO4, and LuPO4. Inorganica Chimica Acta, 60. 39-43 doi:10.1016/s0020-1693(00)91148-4DOI: 10.1016/s0020-1693(00)91148-4
  2. 1993Rasmussen, Svend Erik; Jørgensen, Jens-Erik; Lundtoft, Britta (1993) Refinement of the structure of ScPO4 by powder diffraction by three Rietveld programs. Powder Diffraction, 8 (3). 164-167 doi:10.1017/s088571560001811xDOI: 10.1017/s088571560001811x
  3. 1997Trukhin, A.N., Boatner, L.A. (1997) Electronic Structure of ScPO4 Single Crystals: Optical and Photoelectric Properties. Materials Science Forum, 239. 573-576 doi:10.4028/www.scientific.net/msf.239-241.573DOI: 10.4028/www.scientific.net/msf.239-241.573
  4. 1998Bernhard, Franz, Walter, Franz, Ettinger, Karl, Taucher, Josef, Mereiter, Kurt (1998) Pretulite, ScPO4, a new scandium mineral from the Styrian and Lower Austrian lazulite occurrences, Austria. American Mineralogist, 83 (5-6). 625-630 doi:10.2138/am-1998-5-622 DOI: 10.2138/am-1998-5-622
  5. 2002Moëo, Y., Lulzac, Y., Rouer, O., Palvadeau, P., Gloaguen, E., Leone, P. (2002) Scandium mineralogy: pretulite with scandian zircon and xenotime-(Y) within an apatite-rich oolitic ironstone from Saint-Aubin-des-Châteaux, Armorican Massif, France. The Canadian Mineralogist, 40 (6). 1657-1673 doi:10.2113/gscanmin.40.6.1657 DOI: 10.2113/gscanmin.40.6.1657
