Xenotime-(Yb)

Yb(PO4)
IMA status
  • Approved
IMA symbol
Xtm-Yb
Also known as
  • IMA1998-049

Where it forms, where it's found

Geological setting

Niobium-yttrium-fluorine (NYF) family of rare-element granitic pegmatite.

Type locality
Shatford Lake pegmatites
  1. Shatford Lake
  2. Lac-du-Bonnet area
  3. Manitoba
  4. Canada

50.3810°, -95.4870°

7recorded occurrences
Source · OpenStreetMap

Physical

Lustre
Vitreous
Transparency
Transparent
Colour
Colourless to yellow · light brown
Streak
white
Tenacity
brittle
Cleavage
None Observed
Fracture
Irregular/Uneven
Density
5.85 g/cm³

Optical

Optical type
Uniaxial (+)
Refractive index
1.715 – 1.802
Surface relief
High
Principal indices
nω 1.715 · nε 1.802
Pleochroism
Non-pleochroic
Michel-Lévy diagramhighlighted lineδ = 0.0870
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]870 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation870 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Tetragonal
Space group
I41/amd
Cell parameters
a = 6.866(2) Å · c = 6.004(3) Å
Z
4
Morphology

isolated ~20 μm grains and in aggregates to 50 μm.

Type-locality form

Granular aggregates <= 50 µm across and as isolated small (~20 µm) grains encased in clots of ferrian muscovite.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
70YbYtterbiumYtterbium1173.045173.045
64.56%
8OOxygenOxygen415.99963.996
23.88%
15PPhosphorusPhosphorus130.97430.974
11.56%
Total268.015100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1998-049

In other languages

German
IMA 1998-049 · Xenotim-(Yb)
Italian
Xenotime- · xenotime-(Yb)

Classification

Strunz
10th ed.

8.AD.35

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.APhosphates, etc. without additional anions, without H2ODivision
  • 8.ADWith only large cationsGroup
  • 8.AD.35Xenotime-(Yb)Species

Group, growth & confusion

Literature, links & citation

Citations
  1. 1999Buck, H. M., Cooper, M. A., Černý, P., Grice, J. D., Hawthorne, F. C. (1999) Xenotime-(Yb), YbPO4, a new mineral from the Shatford Lake pegmatite group, southeastern Manitoba, Canada. The Canadian Mineralogist, 37 (5) 1303-1306
  2. 2021(2021) Xenotime-(Yb). Handbook of Mineralogy. Mineralogical Society of America
