Chernovite-(Y)

Y(AsO4)
IMA status
  • Approved
IMA symbol
Chv-Y
Also known as
  • Chernoviet-(Y)
  • IMA1967-027

Where it forms, where it's found

Geological setting

In piemontite veinlets in liparite prophyry.

Type locality
Nyarta-Syu-Yu River
  1. Tel'pos-Iz Mt
  2. Tyumen Oblast
  3. Russia
61recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789104 – 5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Colorless · pale yellow

May show color zoning.

Streak
White
Tenacity
brittle
Cleavage
Perfect

(010).

Density
4.866 g/cm³

Optical

Optical type
Uniaxial (+)
Refractive index
1.783 – 1.879
Surface relief
Very high
Principal indices
nω 1.783 · nε 1.879
Pleochroism
Weak

ε = colorless; ω = pale rose-yellow.

Michel-Lévy diagramhighlighted lineδ = 0.0960
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]960 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation960 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Tetragonal
Space group
#178
Cell parameters
a = 7.05 Å · c = 6.25 Å
Z
4
Morphology

Type material: Prismatic crystals showing forms include (010), (011), and (001), sometimes with narrow rough (110).

Translation gliding
(001)
Type-locality form

Prismatic crystals, generally 0.25 mm and maximum 0.65 mm in size.

Comment

Range: a = 6.99–7.09 c = 6.17–6.32 A.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
39YYttriumYttrium188.90688.906
39.02%
33AsArsenicArsenic174.92274.922
32.89%
8OOxygenOxygen415.99963.996
28.09%
Total227.824100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Chernoviet-(Y)
  • IMA1967-027

In other languages

French
Chernovite- · Chernovite-(Y)
German
Chernovit-(Y) · IMA 1967-027
Italian
Chernovite- · Chernovite-(Y)
Chinese
砷钇石

Classification

Strunz
10th ed.

8.AD.35

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.APhosphates, etc. without additional anions, without H2ODivision
  • 8.ADWith only large cationsGroup
  • 8.AD.35Chernovite-(Y)Species
Dana
8th ed.

38.04.11.02

  • 38Anhydrous Normal Phosphates, Arsenates, and VanadatesClass
  • 38.04AXO4Type
  • 38.04.11Zenotime Group (Tetragonal: I41/amd)Group
  • 38.04.11.02Chernovite-(Y)Species
CIM

20.4.12

  • 20Arsenates (also arsenates with phosphate, but without other anions)Class
  • 20.4Arsenates of Group III metals (Al, rare earths)Group
  • 20.4.12Chernovite-(Y)Species

Group, growth & confusion

Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1934Strada, M., Schwendimann, G. (1934) La struttura cristallina di alcuni fosfati ed arseniati di metalli trivalenti. II. Arseniato e fosfato di ittrio. Gazzetta Chimica Italiana, 64, 662-674. (n Russian)
  2. 1967Goldin, B.A., Yushkin, N.P., Fishman, M.V. (1967) A new yttrium mineral, chernovite. Zapiski Vsesoyuznogo Mineralogicheskogo Obshchestva, 96, 699-704.
  3. 1968Fleischer, Michael (1968) New Mineral Names. American Mineralogist, 53 (9-10) 1775-1780
  4. 1973Graeser, S., Schwander, H., Stalder, H.A. (1973) A solid solution series between xenotime (YtPO4) and chernovite (YtAsO4). Mineralogical Magazine: 39(302): 145-151.
  5. 1987Nickel, Ernest H., Mandarino, Joseph A. (1987) Procedures involving the IMA Commission on New Minerals and Mineral Names and guidelines on mineral nomenclature. American Mineralogist, 72 (9-10) 1031-1042
