Antigorite

Mg3Si2O5(OH)4
IMA status
  • Approved
  • Grandfathered
IMA symbol
Atg
Discovered
1840
Also known as
  • Baltimorit
  • Baltimorita
  • Baltimorite
  • +17 more

Where it forms, where it's found

Geological setting

Serpentinite.

Type locality
Antigorio Valley
  1. Verbano-Cusio-Ossola Province
  2. Piedmont
  3. Italy
697recorded occurrences
Source · OpenStreetMap

Varieties

Physical

Hardness
123456789103.5 – 4/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Green · green-blue · white · brown · black
Streak
Greenish white
Cleavage
Distinct/Good

[001] good

Fracture
Splintery
Density
2.5 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 20 – 50°
Refractive index
1.555 – 1.573
Surface relief
Moderate
Principal indices
nα 1.555 – 1.567 · nβ 1.56 – 1.573 · nγ 1.56 – 1.573
Dispersion
weak
Michel-Lévy diagramhighlighted lineδ = 0.0055
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]55 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation55 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
#4
Cell parameters
a = 43.53 Å · b = 9.25 Å · c = 7.26 Å
Cell angles
β = 91.13 °
Ratio a:b:c
1 : 0.212 : 0.167
Type-locality form

Massive, scales, plates.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen915.999143.991
51.96%
12MgMagnesiumMagnesium324.30572.915
26.31%
14SiSiliconSilicon228.08556.170
20.27%
1HHydrogenHydrogen41.0084.032
1.46%
Total277.108100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Ni
  • Al
  • Mn

Synonyms

  • Baltimorit
  • Baltimorita
  • Baltimorite
  • Bastard Asbestos
  • Blätterserpentin
  • Eisengymnit
  • Gymnita
  • Porcellophit
  • Porcellophita
  • Porcellophite
  • Protoantigorite
  • Septeantigorit
  • Septeantigorita
  • Septeantigorite
  • Thermophyllite
  • Yu yen shi stone
  • Yu yen stone
  • Zermattit
  • Zermattita
  • Zermattite

In other languages

French
antigorite
German
Antigorit
Spanish
Antigorita
Italian
Antigorite
Portuguese
Antigorite
Japanese
葉蛇紋石
Chinese
叶蛇纹石
Russian
Антигорит
Arabic
أنتيغوريت

Classification

Strunz
10th ed.

9.ED.15

  • 9SilicatesClass
  • 9.EPhyllosilicatesDivision
  • 9.EDPhyllosilicates with kaolinite layers composed of tetrahedral and octahedral netsGroup
  • 9.ED.15AntigoriteSpecies
Dana
8th ed.

71.01.2a.01

  • 71Phyllosilicates Sheets of Six-membered RingsClass
  • 71.01Sheets of 6-membered rings with 1:1 layersType
  • 71.01.2a— unnamed intermediate level —Group
  • 71.01.2a.01AntigoriteSpecies
CIM

14.4.15

  • 14Silicates not Containing AluminumClass
  • 14.4Silicates of MgGroup
  • 14.4.15AntigoriteSpecies

Group, growth & confusion

Often grow together
1 mineral
Commonly confused with
2 minerals

Literature, links & citation

Citations
  1. 1840Schweizer, Eduard (1840) Ueber den Antigorit, ein neues Mineral. Annalen der Physik und Chemie, 125. 595-599 doi:10.1002/andp.18401250415DOI: 10.1002/andp.18401250415
  2. 1954Zussman, J. (1954) Investigation of the crystal structure of antigorite. Mineralogical Magazine and Journal of the Mineralogical Society, 30 (227) 498-512 doi:10.1180/minmag.1954.030.227.02 DOI: 10.1180/minmag.1954.030.227.02
  3. 1956Kunze, Günther (1956) Die gewellte Struktur des Antigorits, I. Zeitschrift für Kristallographie - Crystalline Materials, 108 (1) 82-107 doi:10.1524/zkri.1956.108.1-2.82DOI: 10.1524/zkri.1956.108.1-2.82
  4. 1958Kunze, Günther (1958) Die gewellte Struktur des Antigorits. III. Zeitschrift für Kristallographie, 110 (1). 282-320 doi:10.1524/zkri.1958.110.1-6.282DOI: 10.1524/zkri.1958.110.1-6.282
  5. 1958KUNZE, GÜNTHER (1958) Die gewellte Struktur des Antigorits. II. Zeitschrift für Kristallographie, 110 (1-6). 282-320 doi:10.1524/zkri.1958.110.16.282DOI: 10.1524/zkri.1958.110.16.282
Cite this entry
@misc{mineral2026,
  author    = {Mineral Index editorial board},
  title     = {Antigorite — Mineral Index},
  year      = {2026},
  url       = {https://mineralindex.org/minerals/antigorite-260},
  note      = {Accessed 2026-05-11}
}
