Brindleyite

(Ni,Al)3(Si,Al)2O5(OH)4
IMA status
  • Approved
IMA symbol
Bly
Discovered
1967
Also known as
  • Brindleyiet
  • IMA1975-009a
  • Nimesit
  • +2 more

Where it forms, where it's found

Geological setting

Coating on limestone and veinlets cutting kaolinitic clays at the base of a bauxite deposit developed on karst.

Type locality
Marmara bauxite deposit
  1. Megara
  2. West Attica
  3. Attica
  4. Greece

37.9826°, 23.2846°

5recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789102.5 – 3/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Dark yellow-green
Density
3.17 g/cm³

Optical

Optical type
Biaxial
Refractive index
1.635
Surface relief
Moderate
Principal indices
nβ 1.635
Dispersion
r > v

Crystallography

Crystal system
Monoclinic
Cell parameters
a = 5.28 Å · b = 9.13 Å · c = 7.31 Å
Cell angles
β = 104.25 °
Ratio a:b:c
1 : 1.729 : 1.384
Type-locality form

Green coatings to 12 mm thick on limestone. It has a clayey appearance, but often is compact with a pronounced schistosity and lustrous surface.

Comment

Monoclinic or hexagonal. Point Group: n.d. Space Group: n.d. 1M and 3A assumed

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
28NiNickelNickel358.693176.079
34.18%
8OOxygenOxygen915.999143.991
27.95%
13AlAluminiumAluminium526.982134.910
26.19%
14SiSiliconSilicon228.08556.170
10.90%
1HHydrogenHydrogen41.0084.032
0.78%
Total515.182100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Mg
  • Fe
  • Ti
  • La
  • Cr
  • Ca

Synonyms

  • Brindleyiet
  • IMA1975-009a
  • Nimesit
  • Nimesita
  • Nimesite

In other languages

French
Brindleyite
German
Brindleyit · IMA 1975-009a · Nimesit
Italian
Brindleyite

Classification

Strunz
10th ed.

9.ED.15

  • 9SilicatesClass
  • 9.EPhyllosilicatesDivision
  • 9.EDPhyllosilicates with kaolinite layers composed of tetrahedral and octahedral netsGroup
  • 9.ED.15BrindleyiteSpecies
Dana
8th ed.

71.01.2c.03

  • 71Phyllosilicates Sheets of Six-membered RingsClass
  • 71.01Sheets of 6-membered rings with 1:1 layersType
  • 71.01.2c— unnamed intermediate level —Group
  • 71.01.2c.03BrindleyiteSpecies
CIM

16.25.1

  • 16Silicates Containing Aluminum and other MetalsClass
  • 16.25Aluminosilicates of NiGroup
  • 16.25.1BrindleyiteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 1972Maksimovic, Z. (1972) Nimesite, a new septechlorite from a bauxite deposit near Magara, Greece. Bull. Sci. Cons. Acad. Sci. Arts R. S. F. Yusoslav. Sect. A: 17: 224-226.
  2. 1973Fleischer, Michael (1973) New mineral names. American Mineralogist, 58 (11-12) 1111-1115
  3. 1978Maksimovic, Z., Bish, David L. (1978) Brindleyite, a nickel-rich aluminous serpentine mineral analogous to berthierine. American Mineralogist, 63 (5-6) 484-489
  4. 1990Wiewióra, A. (1990) Crystallochemical classifications of phyllosilicates based on the unified system of projection of chemical composition: III. The serpentine-kaolin group. Clay Minerals, 25 (1) 93-98 doi:10.1180/claymin.1990.025.1.10DOI: 10.1180/claymin.1990.025.1.10
  5. 2001(2001) Brindleyite. Handbook of Mineralogy. Mineralogical Society of America
