Cronstedtite

(Fe2+,Fe3+)3(Si,Fe3+)2O5(OH)4
IMA status
  • Approved
  • Grandfathered
IMA symbol
Cro
Discovered
1821
Also known as
  • Chloro-melane
  • Cronstedit
  • Cronstedite
  • +5 more

Where it forms, where it's found

Geological setting

Low temperature hydrothermal mineral.

Type locality
Příbram District
  1. Central Bohemian Region
  2. Czech Republic

49.6883°, 14.0092°

64recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent · Opaque
Colour
Black · dark brown-black · green-black
Streak
Dark olive-green
Tenacity
elastic
Cleavage
Perfect

on (001)

Fracture
Micaceous
Density
3.34 g/cm³

Optical

Optical type
Biaxial (-)
Refractive index
1.72 – 1.8
Surface relief
High
Principal indices
nα 1.72 · nβ 1.80 · nγ 1.80
Birefringence
0.08
Pleochroism
Visible

In brown and blacks

Dispersion
r < v moderate
UV response
Not fluorescent in UV
Michel-Lévy diagramhighlighted lineδ = 0.0800
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]800 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation800 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Trigonal
Space group
#82
Cell parameters
a = 5.49 Å · b = 9.51 Å · c = 7.32 Å
Cell angles
β = 104.51 °
Ratio a:b:c
1 : 1.732 : 1.333
Morphology

Pseudohexagonal prisms, divergent fibrous groups, "cylindrical", reniform, massive. Many polytypes are known and pedion faces may be triangular or pseudohexagonal.

Twinning

Twin axis [100], interpenetrating trigonal pyramids.

Comment

Stacking polytypes; 2H1: P63cm; 2H2: P63; 3T: P31; 1M: Cm; 6T2: P31

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
26FeIronIron855.845446.760
68.63%
8OOxygenOxygen915.999143.991
22.12%
14SiSiliconSilicon228.08556.170
8.63%
1HHydrogenHydrogen41.0084.032
0.62%
Total650.953100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Al
  • Ca

Synonyms

  • Chloro-melane
  • Cronstedit
  • Cronstedite
  • Lillite
  • Melanglimmer
  • Sideroschisolita
  • Sideroschisolite
  • Sideroschisolith

In other languages

French
cronstedtite
German
Cronstedtit
Spanish
Cronstedita · Cronstedtita
Italian
Cronstedtite
Chinese
克铁蛇纹石

Classification

Strunz
10th ed.

9.ED.15

  • 9SilicatesClass
  • 9.EPhyllosilicatesDivision
  • 9.EDPhyllosilicates with kaolinite layers composed of tetrahedral and octahedral netsGroup
  • 9.ED.15CronstedtiteSpecies
Dana
8th ed.

71.01.04.07

  • 71Phyllosilicates Sheets of Six-membered RingsClass
  • 71.01Sheets of 6-membered rings with 1:1 layersType
  • 71.01.04Allophane groupGroup
  • 71.01.04.07CronstedtiteSpecies
CIM

14.19.7

  • 14Silicates not Containing AluminumClass
  • 14.19Silicates of FeGroup
  • 14.19.7CronstedtiteSpecies

Group, growth & confusion

Often grow together
5 minerals
Commonly confused with
2 minerals

Literature, links & citation

Citations
  1. 1962Frondel, Cliford (1962) Polytypism in cronstedtite. American Mineralogist, 47 (5-6) 781-782
  2. 1963Steadman, R., Nuttall, P. M. (1963) Polymorphism in cronstedtite. Acta Crystallographica, 16 (1) 1-8 doi:10.1107/s0365110x63000013DOI: 10.1107/s0365110x63000013
  3. 1964Steadman, R., Nuttall, P. M. (1964) Further polymorphism in cronstedtite. Acta Crystallographica, 17 (4) 404-406 doi:10.1107/s0365110x64000913DOI: 10.1107/s0365110x64000913
  4. 1981MacKenzie, K.J.D., Berezowski, R.M. (1981) Thermal and Mossbauer studies of iron-containing hydrous silicates. III. Cronstedtite. Thermochimica Acta, 44. 171-187 doi:10.1016/0040-6031(81)80039-1DOI: 10.1016/0040-6031(81)80039-1
  5. 1988Mineralogical Record (1988): 19: 169.
