Arsendescloizite

PbZn(AsO4)(OH)
IMA status
  • Approved
IMA symbol
Adcz
Discovered
1982
Also known as
  • Arsendescloiziet
  • Arsendescloizitt
  • IMA1979-030

Where it forms, where it's found

Geological setting

Oxidized zone of a polymetallic ore arsenic-bearing sulfide deposit

Type locality
Tsumeb Mine (Ongopolo Mine)
  1. Tsumeb
  2. Oshikoto Region
  3. Namibia

-19.2270°, 17.7276°

27recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789104/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Brilliant · subadamantine.
Transparency
Transparent
Colour
Pale yellow to deep green · greyish brown

Colour depending on impurity contents, especially Cu.

Streak
White
Cleavage

None

Density
6.57 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 30° · 2V calc = 38°
Refractive index
1.99 – 2.035
Surface relief
Very high
Principal indices
nα 1.990 · nβ 2.030 · nγ 2.035
Birefringence
0.045
Pleochroism
Non-pleochroic
Dispersion
r > v
Extinction
XYZ = bac
Luminescence
None.
UV response
Not fluorescent.
Michel-Lévy diagramhighlighted lineδ = 0.0450
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]450 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation450 nm
Order1st order
XPL colour

Crystallography

Crystal system
Orthorhombic
Space group
P21 21 21
Cell parameters
a = 6.075 Å · b = 9.358 Å · c = 7.634 Å
Ratio a:b:c
1 : 1.540 : 1.257
Z
4
Morphology

Platy to wedge-shaped crystals. Platy (100) to 1 mm; also with (101). (110), (100), (111).

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
82PbLeadLead1207.200207.200
48.35%
8OOxygenOxygen515.99979.995
18.67%
33AsArsenicArsenic174.92274.922
17.48%
30ZnZincZinc165.38065.380
15.26%
1HHydrogenHydrogen11.0081.008
0.24%
Total428.505100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Arsendescloiziet
  • Arsendescloizitt
  • IMA1979-030

In other languages

German
Arsendescloizit · IMA 1979-030
Italian
Arsendescloizite
Japanese
砒デクロワゾー石
Chinese
砷锌铅矿 · 羟砷锌铅石

Classification

Strunz
10th ed.

8.BH.35

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.BPhosphates, etc., with additional anions, without H2ODivision
  • 8.BHWith medium-sized and large cations, (OH,etc.):RO4 = 1:1Group
  • 8.BH.35ArsendescloiziteSpecies
Dana
8th ed.

41.05.01.09

  • 41Anhydrous Phosphates, Etc.containing Hydroxyl or HalogenClass
  • 41.05(AB)2(XO4)ZqType
  • 41.05.01Adelite GroupGroup
  • 41.05.01.09ArsendescloiziteSpecies
CIM

20.5.6

  • 20Arsenates (also arsenates with phosphate, but without other anions)Class
  • 20.5Arsenates of Ti and PbGroup
  • 20.5.6ArsendescloiziteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 1982Dunn, Pete J., Keller, Paul (1982) Arsendescloizite, a new mineral from Tsumeb [Namibia]. The Mineralogical Record, 13 (3) 155-157
  2. 1983Fleischer, Michael, Pabst, Adolf (1983) New Mineral Names. American Mineralogist, 68 (1-2) 280-283
  3. 2003Keller, Paul, Lissner, Falk, Schleid, Thomas (2003) The crystal structure of arsendescloizite, PbZn(OH)[AsO4], from Tsumeb (Namibia) Neues Jahrbuch für Mineralogie - Monatshefte, 2003 (8) 374-384 doi:10.1127/0028-3649/2003/2003-0374DOI: 10.1127/0028-3649/2003/2003-0374
  4. 2005(2005) Arsendescloizite. Handbook of Mineralogy. Mineralogical Society of America
