Gottlobite

CaMg(VO4)(OH)
IMA status
  • Approved
IMA symbol
Got
IMA approved
1998
Also known as
  • Gottlobiet
  • IMA1998-066

Where it forms, where it's found

Geological setting

Hydrothermal barite veins that cut conglomerate.

Type locality
Glücksstern Mine
  1. Gottlob Hill
  2. Friedrichroda
  3. Gotha District
  4. Thuringia
  5. Germany

50.8518°, 10.5695°

1recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Adamantine
Transparency
Transparent
Colour
Orange to orange-brown
Streak
Brownish white
Cleavage
None Observed
Fracture
Irregular/Uneven · Conchoidal
Density
3.46 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = Very large° · 2V calc = 62 – 80°
Refractive index
1.797 – 1.828
Surface relief
Very high
Principal indices
nα 1.797 · nβ 1.805 – 1.815 · nγ 1.828
Pleochroism
Visible

X = orange-brown, Y = pale yellowish brown, Z = orange-brown.

Dispersion
r > v medium
Notes

Absorption: Z ≥ X > Y.

Michel-Lévy diagramhighlighted lineδ = 0.0310
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]310 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation310 nm
Order1st order
XPL colour

Crystallography

Crystal system
Orthorhombic
Space group
#44
Cell parameters
a = 7.501 Å · b = 9.01 Å · c = 5.941 Å
Ratio a:b:c
1 : 1.201 : 0.792
Unit cell volume
401.5 ų
Z
4
Morphology

Forms: (010) dominant, (110), (011), (111), (111) and (101).

Twinning

None observed.

Type-locality form

Equant to tabular crystals and equant grains (up to 0.5 mm).

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen515.99979.995
40.75%
23VVanadiumVanadium150.94250.942
25.95%
20CaCalciumCalcium140.07840.078
20.41%
12MgMagnesiumMagnesium124.30524.305
12.38%
1HHydrogenHydrogen11.0081.008
0.51%
Total196.328100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Gottlobiet
  • IMA1998-066

In other languages

German
Gottlobit · IMA 1998-066
Italian
Gottlobite
Japanese
ゴットロバイト
Chinese
釩砷钙鎂石 · 钒砷钙镁石

Classification

Strunz
10th ed.

8.BH.35

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.BPhosphates, etc., with additional anions, without H2ODivision
  • 8.BHWith medium-sized and large cations, (OH,etc.):RO4 = 1:1Group
  • 8.BH.35GottlobiteSpecies

Group, growth & confusion

Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 2000Witzke, T., Steins, M., Doering, T., Kolitsch, U. (2000) Gottlobite, CaMg(VO4,AsO4)(OH), a new mineral from Friedrichroda, Thuringia, Germany. Neues Jahrbuch für Mineralogie - Monatshefte: 2000: 444-454.
  2. 2021(2021) Gottlobite. Handbook of Mineralogy. Mineralogical Society of America
