Artinite

Mg2(CO3)(OH)2 · 3H2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Art
Discovered
1902
Also known as
  • Artiniet
  • Artinitt

Where it forms, where it's found

Geological setting

A low-temperature mineral in weathered or altered ultramafic rocks, typically serpentinites.

Low-temperature hydrothermal environments as veinlets or crusts along fracture surfaces in serpentinized ultrabasic rocks.

Type locality
Dossi di Franscia
  1. Franscia
  2. Lanzada
  3. Sondrio Province
  4. Lombardy
  5. Italy

46.2882°, 9.9043°

55recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789102.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous · Silky
Transparency
Transparent
Colour
White · colourless in transmitted light
Streak
White
Tenacity
brittle
Cleavage
Perfect

On (100) perfect; on (001) good.

Density
2.01 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 71° · 2V calc = 68°
Refractive index
1.488 – 1.557
Surface relief
Moderate
Principal indices
nα 1.488 – 1.489 · nβ 1.533 – 1.534 · nγ 1.556 – 1.557
Dispersion
none
Notes

Optic axis nearly perpendicular to (100).

Michel-Lévy diagramhighlighted lineδ = 0.0680
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]680 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation680 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
C2/m
Cell parameters
a = 16.56 Å · b = 3.15 Å · c = 6.22 Å
Cell angles
β = 99.15 °
Ratio a:b:c
1 : 0.190 : 0.376
Z
1
Morphology

Forms crusts of acicular crystals, elongated [010]. Also botryoidal masses of silky fibers; spherical aggregates of radiating fibers; cross-fiber veinlets.

Type-locality form

Acicular crystals forming cross-fiber veinlets, botyroidal crusts, and spherical or bow tie aggregates of divergent crystals.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen815.999127.992
65.08%
12MgMagnesiumMagnesium224.30548.610
24.71%
6CCarbonCarbon112.01112.011
6.11%
1HHydrogenHydrogen81.0088.064
4.10%
Total196.677100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Artiniet
  • Artinitt

In other languages

French
artinite
German
Artinit
Spanish
Artinita
Italian
artinite
Portuguese
Artinite
Japanese
アルチニ石
Chinese
水碳镁石

Classification

Strunz
10th ed.

5.DA.10

  • 5CarbonatesClass
  • 5.DCarbonates with additional anions, with H2ODivision
  • 5.DAWith medium-sized cationsGroup
  • 5.DA.10ArtiniteSpecies
Dana
8th ed.

16b.03.01.01

  • 16bHydrated Carbonates Containing Hydroxyl or HalogenClass
  • 16b.03AmBn(XO3)pZqxH2O & with (m+n):p = 2:1Type
  • 16b.03.01— unnamed intermediate level —Group
  • 16b.03.01.01ArtiniteSpecies
CIM

11.3.6

  • 11CarbonatesClass
  • 11.3Carbonates of MgGroup
  • 11.3.6ArtiniteSpecies

Group, growth & confusion

Often grow together
8 minerals

Literature, links & citation

Citations
  1. 1902Brugnatelli, S.C.L. (1902) Sopra un nuovo minerale delle cave d´amianto della Valle Lanterna. Rendiconti Reale Istituto Lombardo di Scienze e Lettere (Milano): 35: 869-874. (in Italian)
  2. 1903Brugnatelli, S.C.L. (1903) Idromagnesite ed artinite di Emorese [Val d'Aosta]. 1st. Lombardo, Rendus: 36: 824. (in Italian)
  3. 1921Larsen, Esper S. (1921) The microscopic determination of the nonopaque minerals. Bulletin 679. US Geological Survey doi:10.3133/b679 DOI: 10.3133/b679
  4. 1927Fenoglio, M. (1927) Sopra alcuni minerali di Viu in Val di Lanzo. Bollettino della Societa Geologica d'Italia: 46: 13-23. (in Italian)
  5. 1930Lincio, A. (1930) Sull'artinite di Monte Ramazzo (Liguria). Reale accademia nazionale dei Lincei, Att., Rome: 11: 420-424 (in Italian).
