Beaverite-(Cu)

Pb(Fe3+2Cu)(SO4)2(OH)6
IMA status
  • Approved
  • Grandfathered
IMA symbol
Bvr-Cu
Discovered
1911
Also known as
  • Beaveriet-(Cu)
  • Beaverit
  • Beaverita
  • +1 more

Where it forms, where it's found

Geological setting

Secondary mineral in a polymetallic deposit.

Oxidized zone of Pb-Zn deposits in arid regions.

Type locality
Horn Silver Mine
  1. Frisco
  2. San Francisco Mining District
  3. Beaver County
  4. Utah
  5. USA

38.4497°, -113.2756°

167recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789103.5 – 4.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Earthy
Colour
Yellow
Density
4.36 g/cm³

Optical

Optical type
Uniaxial (-)
Refractive index
1.83 – 1.87
Surface relief
Very high
Principal indices
nω 1.85 · nε 1.83 – 1.87
Birefringence
Strong.
Pleochroism
Visible

O= Dark yellow E= Pale yellow

Michel-Lévy diagramhighlighted lineδ = 0.0000
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]0 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation0 nm
Order1st order
XPL colour

Crystallography

Crystal system
Trigonal
Space group
#99
Cell parameters
a = 7.2(5) Å · c = 16.994(32) Å
Z
3
Morphology

Earthy and friable masses comprised of microscopic hexagonal plates.

Type-locality form

Occasionally found pure in small, friable masses. Minute, canary yellow, six-sided plates.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1415.999223.986
33.11%
82PbLeadLead1207.200207.200
30.62%
26FeIronIron255.845111.690
16.51%
16SSulfurSulfur232.06064.120
9.48%
29CuCopperCopper163.54663.546
9.39%
1HHydrogenHydrogen61.0086.048
0.89%
Total676.590100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Beaveriet-(Cu)
  • Beaverit
  • Beaverita
  • Beaverite

In other languages

German
Beaverit-(Cu) · IMA 07-D
Italian
beaverite · Beaverite- · beaverite-(Cu)

Classification

Strunz
10th ed.

7.BC.10

  • 7SulfatesClass
  • 7.BSulfates (selenates, etc.) with additional anions, without H2ODivision
  • 7.BCWith medium-sized and large cationsGroup
  • 7.BC.10Beaverite-(Cu)Species
Dana
8th ed.

30.02.05.07

  • 30Anhydrous Sulfates Containing Hydroxyl or HalogenClass
  • 30.02(AB)2(XO4)ZqType
  • 30.02.05Alunite Group (Jarosite Subgroup)Group
  • 30.02.05.07Beaverite-(Cu)Species
CIM

25.7.12

  • 25SulphatesClass
  • 25.7Sulphates of PbGroup
  • 25.7.12Beaverite-(Cu)Species

Group, growth & confusion

Literature, links & citation

Citations
  1. 1911Butler, B.S. and Schaller, W.T. (1911) Beaverite, a new mineral. Journal of the Washington Academy of Sciences: 1: 26-27.
  2. 1911Butler, B.S., Schaller, W.T. (1911) Some minerals from Beaver County, Utah. American Journal of Science: 32: 418-424.
  3. 1921Larsen, Esper S. (1921) The microscopic determination of the nonopaque minerals. Bulletin 679. US Geological Survey doi:10.3133/b679 DOI: 10.3133/b679
  4. 1957Kingsbury, Arthur W.G., Hartley, J. (1957) Beaverite from the Lake District. Mineralogical Magazine and Journal of the Mineralogical Society, 31 (239). 700-702 doi:10.1180/minmag.1957.31.239.10 DOI: 10.1180/minmag.1957.31.239.10
  5. 1960Kingsbury, Arthur W. G., Hartley, J. (1960) Carminite and beudantite from the northern part of the Lake District and from Cornwall. Mineralogical Magazine and Journal of the Mineralogical Society, 32 (249) 423-432 doi:10.1180/minmag.1960.032.249.01 DOI: 10.1180/minmag.1960.032.249.01
