Bellbergite

(K,Ba,Sr)2Sr2Ca2(Ca,Na)4(Si,Al)36O72 · 30H2O
IMA status
  • Approved
IMA symbol
Blb
Discovered
1993
Also known as
  • Bellbergiet
  • IMA1990-057

Where it forms, where it's found

Geological setting

In leucite tephrite lava at contacts between lava and calcium-rich xenoliths.

Type locality
Seekante
  1. Mayen
  2. Mayen-Koblenz
  3. Rhineland-Palatinate
  4. Germany

50.3331°, 7.2492°

4recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Colourless to white
Streak
White
Cleavage
None Observed
Fracture
Conchoidal
Density
2.2 g/cm³

Optical

Optical type
Uniaxial (-)
Refractive index
1.507 – 1.522
Surface relief
Moderate
Principal indices
nω 1.522 · nε 1.507
Michel-Lévy diagramhighlighted lineδ = 0.0150
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]150 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation150 nm
Order1st order
XPL colour

Crystallography

Crystal system
Hexagonal
Cell parameters
a = 13.244(1) Å · c = 15.988(2) Å
Z
1
Morphology

Hexagonal dipyramidal crystals.

Type-locality form

Hexagonal dipyramidal crystals.

Comment

Point Group: 6/m 2/m 2/m; _6m2; or 6mm; Space Group: P63 /mmc; P63mc; or P_62c

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen10215.9991631.898
34.64%
14SiSiliconSilicon3628.0851011.060
21.46%
13AlAluminiumAluminium3626.982971.352
20.62%
38SrStrontiumStrontium487.620350.480
7.44%
56BaBariumBarium2137.327274.654
5.83%
20CaCalciumCalcium640.078240.468
5.11%
11NaSodiumSodium422.99091.960
1.95%
19KPotassiumPotassium239.09878.196
1.66%
1HHydrogenHydrogen601.00860.480
1.29%
Total4710.548100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Bellbergiet
  • IMA1990-057

In other languages

German
Bellbergit · IMA 1990-057
Italian
bellbergite · IMA1990-057

Classification

Strunz
10th ed.

9.GD.20

  • 9SilicatesClass
  • 9.GTektosilicates with zeolitic H2O; zeolite familyDivision
  • 9.GDChains of 6-membered rings – tabular zeolitesGroup
  • 9.GD.20BellbergiteSpecies
Dana
8th ed.

77.01.08.01

  • 77Tectosilicates ZeolitesClass
  • 77.01Zeolite group - True zeolitesType
  • 77.01.08Unclassified zeolite speciesGroup
  • 77.01.08.01BellbergiteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 1993Rüdinger, B., Tillmanns, E., Hentschel, G., Rüdinger, B., Tillmanns, E., Hentschel, G. (1993) Bellbergite—a new mineral with the zeolite structure type EAB. Mineralogy and Petrology, 48 (2) 147-152 doi:10.1007/bf01163093DOI: 10.1007/bf01163093
  2. 1994Jambor, John L., Roberts, Andrew C., Puziewicz, Jacek (1994) New Mineral Names. American Mineralogist, 79 (5-6) 570-574
  3. 1997Coombs, Douglas S., Alberti, Alberto, Armbruster, Thomas, Artioli, Gilberto, Colella, Carmine, Galli, Ermanno, Grice, Joel D., Liebau, Friedrich, Mandarino, Joseph A., Minato, Hideo, et al. (1997) Recommended nomenclature for zeolite minerals; report of the Subcommittee on Zeolites of the International Mineralogical Association, Commission on New Minerals and Mineral Names. The Canadian Mineralogist, 35 (6). 1571-1606
  4. 1997Mandarino, Joseph A. (1997) New Minerals 1990-1994. The Mineralogical Record Inc., Tuscon, Arizona. 220pp.
  5. 1998Blaß, Günter; Graf, Hans Werner (1998) Bellbergit von der Typlokalität Bellerberg. Eine Zusammenstellung der bisher beobachteten Ausbildungsvarianten [Bellbergite from the type locality Bellerberg. A compilation of the crystal habits observed so far]. Mineralien-Welt, 9 (6). 30-33
