Cowlesite

Ca(Al2Si3)O10 · 5-6H2O
IMA status
  • Approved
IMA symbol
Cow
Discovered
1975
Also known as
  • Cowlesiet
  • IMA1975-016

Where it forms, where it's found

Geological setting

In amygdules in basalt. Also in scoria.

Type locality
North Table Mountain
  1. Golden
  2. Golden Mining District
  3. Jefferson County
  4. Colorado
  5. USA

39.7914°, -105.2008°

86recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105 – 5.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Colourless · white
Streak
White
Tenacity
brittle
Cleavage
Perfect

(010)

Density
2.14 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 44 – 53°
Refractive index
1.505 – 1.518
Surface relief
Moderate
Principal indices
nα 1.505 – 1.513 · nβ 1.509 – 1.516 · nγ 1.509 – 1.518
Dispersion
none
Extinction
X = a; Y = b; Z = c.
Michel-Lévy diagramhighlighted lineδ = 0.0045
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]45 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation45 nm
Order1st order
XPL colour

Crystallography

Crystal system
Orthorhombic
Cell parameters
a = 23.116(8) Å · b = 24.891(7) Å · c = 30.468(2) Å
Ratio a:b:c
1 : 1.077 : 1.318
Morphology

Type material: Simple blades, showing only three forms: (010), (001), and (101). Crystals can exceed 0.3 mm in length and 0.1 mm in width, but thicknesses are less than 2 μm.

Type-locality form

Sometimes visually similar to thomsonite. Thin cavity linings, to 0.5 mm thick, growing as radially oriented blades. As sprays of blades up to 2 mm, and rarely as sprays of delicate, single blades. Blades always < 2 μm thick.

Comment

Space group Ccme (non-standard setting of space group Cmce). Originally reported cell: a 11.27, b 15.25, c 12.61 Å. Originally, a doubled cell with a 23.3, b 30.6, c 25.0 A is also reported (Vezzalini et al., 1992); this was later found to be the true cell..

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1515.999239.985
56.02%
14SiSiliconSilicon328.08584.255
19.67%
13AlAluminiumAluminium226.98253.964
12.60%
20CaCalciumCalcium140.07840.078
9.36%
1HHydrogenHydrogen101.00810.080
2.35%
Total428.362100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Fe
  • Na
  • K

Synonyms

  • Cowlesiet
  • IMA1975-016

In other languages

German
Cowlesit · IMA 1975-016
Spanish
Cowlesita
Italian
cowlesite · IMA1975-016

Classification

Strunz
10th ed.

9.GG.05

  • 9SilicatesClass
  • 9.GTektosilicates with zeolitic H2O; zeolite familyDivision
  • 9.GGUnclassified zeolitesGroup
  • 9.GG.05CowlesiteSpecies
Dana
8th ed.

77.01.05.08

  • 77Tectosilicates ZeolitesClass
  • 77.01Zeolite group - True zeolitesType
  • 77.01.05Natrolite and related speciesGroup
  • 77.01.05.08CowlesiteSpecies
CIM

16.9.28

  • 16Silicates Containing Aluminum and other MetalsClass
  • 16.9Aluminosilicates of CaGroup
  • 16.9.28CowlesiteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 1975Wise, William S., Tschernich, Rudy W. (1975) Cowlesite a new Ca-zeolite. American Mineralogist, 60 (11-12) 951-956
  2. 1984Nawaz, Rab (1984) New data on cowlesite from Northern Ireland. Mineralogical Magazine, 48 (349) 565-566 doi:10.1180/minmag.1984.048.349.19 DOI: 10.1180/minmag.1984.048.349.19
  3. 1992Tschernich, Rudy W. (1992) Zeolites of the World. Geoscience Press, Inc. 567pp.
  4. 1992Vezzalini, Giovanna, Artioli, Gilberto, Quartieri, Simona, Foy, Harry (1992) The crystal chemistry of cowlesite. Mineralogical Magazine, 56 (385) 575-579 doi:10.1180/minmag.1992.056.385.13 DOI: 10.1180/minmag.1992.056.385.13
  5. 1996Rychlý, R., Langrová, A., Had, J. (1996) Chemistry of cowlesite from Zezice, Bohemia. Scripta Facultatis Scientiarum Naturalium Universitatis Masarykianae Brunensis - Geologia: 26: 43-44.
