Breithauptite

NiSb
IMA status
  • Approved
  • Grandfathered
IMA symbol
Bhp
Discovered
1840
Also known as
  • Antimonnicke (of Stromeyer)
  • Antimonnickel (of Stromeyer)
  • Breithhauptite
  • +1 more

Where it forms, where it's found

Geological setting

In hydrothermal veins associated with other nickle and cobalt arsenides.

Type locality
St Andreasberg
  1. Braunlage
  2. Goslar District
  3. Lower Saxony
  4. Germany
189recorded occurrences
Source · OpenStreetMap

Varieties

Physical

Hardness
123456789105.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Opaque
Colour
Copper-red with a violet tint
Streak
Reddish brown
Tenacity
brittle
Fracture
Irregular/Uneven · Sub-Conchoidal
Density
7.591 g/cm³

Optical

Pleochroism
Visible
Anisotropism
noticeable in oil and air
Tropism
Anisotropic
Reflectance R%
(44.9,49.0) 400, (43.1,48.1) 420, (41.4,47.1) 440, (39.6,46.4) 460, (38.2,45.8) 480, (36.9,45.2) 500, (35.9,45.5) 520, (37.4,47.7) 540, (39.5,49.4) 560, (42.0,51.6) 580, (44.5,53.4) 600, (46.8,55.1) 620, (49.1,56.9) 640, (51.1,58.4) 660, (52.6,59.8) 680, (53.9,61.1) 700
Reflected-light panel
43.6 %anisotropic · dual curve
Specimen sRGB 243, 153, 86
White reference100 % reflector under same lamp
R₁ R₂
Mode
Anisotropism
noticeable in oil and air

Crystallography

Crystal system
Hexagonal
Space group
#126
Cell parameters
a = 3.946 Å · c = 5.148 Å
Z
2
Morphology

Thin tabular, arborescent, disseminated, massive

Twinning

Twin plane (1011)

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
51SbAntimonyAntimony1121.760121.760
67.47%
28NiNickelNickel158.69358.693
32.53%
Total180.453100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Fe
  • Co
  • As
  • S

Synonyms

  • Antimonnicke (of Stromeyer)
  • Antimonnickel (of Stromeyer)
  • Breithhauptite
  • Briethauptite (of Fröbel)

In other languages

French
Antimonnicke · Breithauptite · Hartmannite
German
Breithauptit
Spanish
Breithauptita
Italian
Breithauptite
Chinese
红锑镍 · 红锑镍矿
Simplified Chinese
红锑镍矿
Traditional Chinese
紅銻鎳礦 · 銻鎳礦

Classification

Strunz
10th ed.

2.CC.05

  • 2Sulfides and SulfosaltsClass
  • 2.CMetal Sulfides, M: S = 1: 1 (and similar)Division
  • 2.CCWith Ni, Fe, Co, PGE, etc.Group
  • 2.CC.05BreithauptiteSpecies
Dana
8th ed.

02.08.11.02

  • 02SulfidesClass
  • 02.08AmXp, with m:p = 1:1Type
  • 02.08.11Nickeline Group (Hexagonal: P63/mmc)Group
  • 02.08.11.02BreithauptiteSpecies
CIM

3.11.36

  • 3Sulphides, Selenides, Tellurides, Arsenides and Bismuthides (except the arsenides, antimonides and bismuthides of Cu, Ag and Au, which are included in Section 1)Class
  • 3.11Sulphides etc. of NiGroup
  • 3.11.36BreithauptiteSpecies

Group, growth & confusion

In the same group
12 members
Often grow together
6 minerals

Literature, links & citation

Citations
  1. 1845Haidinger, Wilhelm (1845) Zweite Klasse: Geogenide. XIII. Ordnung. Kiese. I. Nickelkies. Breithauptit. In Handbuch der bestimmenden Mineralogie, enthaltend die Terminologie, Systematik, Nomenklatur und Charakteristik der Naturgeschichte des Mineralreiches (1st ed.) Braumüller & Seidel. p.559-562.
  2. 1944Palache, Charles, Berman, Harry, Frondel, Clifford (1944) The System of Mineralogy (7th ed.) Vol. 1 - Elements, Sulfides, Sulfosalts, Oxides. John Wiley and Sons, New York.
  3. 1948Hewitt, Donald F. (1948) A partial study of the NiAs-NiSb system. Economic Geology, 43 (5) 408-417 doi:10.2113/gsecongeo.43.5.408DOI: 10.2113/gsecongeo.43.5.408
  4. 1969Ramdohr, Paul (1969) The Ore Minerals and their Intergrowths. Pergamon Press, Oxford. 1174pp. doi:10.1016/c2013-0-10027-xDOI: 10.1016/c2013-0-10027-x
  5. 2005(2005) Breithauptite. Handbook of Mineralogy. Mineralogical Society of America
