Celleriite

◻(Mn2+2Al)Al6(Si6O18)(BO3)3(OH)3(OH)
IMA status
  • Approved
IMA symbol
Cll
IMA approved
2019
Also known as
  • Celleriiet
  • IMA2019-089

Where it forms, where it's found

Geological setting

Pegmatite

Type locality
Pikárec
  1. Žďár nad Sázavou District
  2. Vysočina Region
  3. Czech Republic
1recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789107/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Colour
Violet to gray-blue · dark brownish-green
Streak
White
Tenacity
brittle
Cleavage
None Observed
Fracture
Conchoidal
Density
3.13 g/cm³

Optical

Optical type
Uniaxial (-)
Refractive index
1.628 – 1.643
Surface relief
Moderate
Principal indices
nω 1.643 · nε 1.628
Pleochroism
Visible

O = pale violet and E = light grey-blue in holotype; O = pale green and E = colorless in co-type

Michel-Lévy diagramhighlighted lineδ = 0.0150
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]150 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation150 nm
Order1st order
XPL colour

Crystallography

Crystal system
Trigonal
Space group
#86
Cell parameters
a = 15.9518(4) Å · c = 7.1579(2) Å
Z
3
Type-locality form

Sectors in other tourmaline crystals.

Synonyms

  • Celleriiet
  • IMA2019-089

In other languages

German
Celleriit · IMA 2019-089

Classification

Strunz
10th ed.

9.CK

  • 9SilicatesClass
  • 9.CCyclosilicatesDivision
  • 9.CK[Si6O18]12- 6-membered single rings, with insular complex anionsGroup
  • 9.CKCelleriiteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 2020Miyawaki, Ritsuro, Hatert, Frédéric, Pasero, Marco, Mills, Stuart J. (2020) IMA Commission on New Minerals, Nomenclature and Classification (CNMNC) – Newsletter 53. European Journal of Mineralogy, 32 (1) 209-213 doi:10.5194/ejm-32-209-2020 DOI: 10.5194/ejm-32-209-2020
  2. 2022(2022) Celleriite. Handbook of Mineralogy. Mineralogical Society of America
  3. 2022Bosi, Ferdinando, Pezzotta, Federico, Altieri, Alessandra, Andreozzi, Giovanni B., Ballirano, Paolo, Tempesta, Gioacchino, Cempírek, Jan, Škoda, Radek, Filip, Jan, Čopjaková, Renata, Novák, Milan, Kampf, Anthony R., Scribner, Emily D., Groat, Lee A., Evans, R. James (2022) Celleriite, ☐(Mn2+2Al)Al6(Si6O18)(BO3)3(OH)3(OH), a new mineral species of the tourmaline supergroup. American Mineralogist, 107 (1) 31-42 doi:10.2138/am-2021-7818DOI: 10.2138/am-2021-7818
