Ertlite

NaAl3Al6(Si4B2O18)(BO3)3(OH)3O
IMA status
  • Approved
IMA symbol
Etl
Also known as
  • Ertliet
  • IMA2023-086

Where it forms, where it's found

Geological setting

A late-stage hydrothermal phase in open pockets within highly fractionated, B-rich granitic pegmatite dike of lithium-cesium-tantalum-enriched type (LCT-type).

Type locality
Sakangyi
  1. Kyauk-Pyat-That
  2. Mogok Township
  3. Pyin-Oo-Lwin District
  4. Mandalay Region
  5. Myanmar

22.9008°, 96.3472°

3recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789107 – 8/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
pink · yellowish-brown to grey or near-colorless
Streak
white
Tenacity
brittle
Fracture
Conchoidal
Density
3.128 g/cm³

Optical

Optical type
Uniaxial (-)
Refractive index
1.639 – 1.6624
Surface relief
High
Principal indices
nω 1.6624 · nε 1.639
Pleochroism
Weak

slightly pleochroic in plane-polarized transmitted light, featuring a pale gray in the omega direction and colorless in the epsilon direction

UV response
a weak dark red fluorescence under short-wave UV light.
Notes

ω = 1.6624(5) and ε = 1.6541(3) (co-type)

Michel-Lévy diagramhighlighted lineδ = 0.0234
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]234 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation234 nm
Order1st order
XPL colour

Crystallography

Crystal system
Trigonal
Space group
#86
Cell parameters
a = 15.6509(8) Å · c = 7.0406(5) Å
Unit cell volume
1493.55 ų
Z
3
Type-locality form

euhedral crystals and aggregates, up to 10 mm in diameter

Comment

Parameters of type specimen from Madagascar; co-type from Myanmar has: a = 15.590(2), c = 7.009(1) Å, V = 1475.3(4) Å3.

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen3115.999495.969
53.26%
13AlAluminiumAluminium926.982242.838
26.08%
14SiSiliconSilicon428.085112.340
12.06%
5BBoronBoron510.81054.050
5.80%
11NaSodiumSodium122.99022.990
2.47%
1HHydrogenHydrogen31.0083.024
0.33%
Total931.211100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From Mindat formula

Synonyms

  • Ertliet
  • IMA2023-086

In other languages

German
Ertlit

Classification

Strunz
10th ed.

9.CK.05

  • 9SilicatesClass
  • 9.CCyclosilicatesDivision
  • 9.CK[Si6O18]12- 6-membered single rings, with insular complex anionsGroup
  • 9.CK.05ErtliteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. Cempírek, J., Jonsson, E., Skřápková, L., Škoda, R., Čopjaková, R., Groat, L.A., Kampf, A.R., Lussier, A.J., Hawthorne, F.C. and Haifler, J. (2024) Ertlite, IMA 2023-086. CNMNC Newsletter 79, Mineralogical Magazine, 88
  2. 2025Cempírek, Jan; Jonsson, Erik; Skřápková, Lenka; Škoda, Radek; Kolitsch, Uwe; Čopjaková, Renata; Groat, Lee A.; Kampf, Anthony R.; Lussier, Aaron J.; Hawthorne, Frank C.; et al. (2025) Ertlite, NaAl3Al6(Si4B2O18)(BO3)3(OH)3O, a new mineral species of the tourmaline supergroup. American Mineralogist, 110 (12). 1865-1876 doi:10.2138/am-2025-9816DOI: 10.2138/am-2025-9816
