Darrellhenryite

Na(Al2Li)Al6(Si6O18)(BO3)3(OH)3O
IMA status
  • Approved
IMA symbol
Dhry
IMA approved
2012
Also known as
  • Darrellhenryiet
  • IMA2012-026

Where it forms, where it's found

Geological setting

Complex Li-bearing pegmatite, petalite-subtype

Li-rich pegmatites

Type locality
Nová Ves pegmatite
  1. Nová Ves
  2. Český Krumlov District
  3. South Bohemian Region
  4. Czech Republic

48.9475°, 14.2522°

8recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789107/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
intense to pale pink
Streak
pinkish white
Tenacity
brittle
Fracture
Conchoidal
Density
3.03 g/cm³

Optical

Optical type
Uniaxial (-)
Refractive index
1.619 – 1.636
Surface relief
Moderate
Principal indices
nω 1.636 · nε 1.619
Birefringence
0.017
Pleochroism
Weak

colorless (||c) to pale pink (^c)

UV response
none
Notes

Chromophore believed to be Mn

Michel-Lévy diagramhighlighted lineδ = 0.0170
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]170 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation170 nm
Order1st order
XPL colour

Crystallography

Crystal system
Trigonal
Space group
R3m
Cell parameters
a = 15.823(1) Å · c = 7.095(1) Å
Z
3
Type-locality form

subhedral, short, columnar crystals and parallel aggregates, up to 3 cm long and up to 2 cm thick

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen3115.999495.969
52.44%
13AlAluminiumAluminium826.982215.856
22.83%
14SiSiliconSilicon628.085168.510
17.82%
5BBoronBoron310.81032.430
3.43%
11NaSodiumSodium122.99022.990
2.43%
3LiLithiumLithium16.9406.940
0.73%
1HHydrogenHydrogen31.0083.024
0.32%
Total945.719100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Darrellhenryiet
  • IMA2012-026

In other languages

German
Darrellhenryit · IMA 2012-026
Italian
darrellhenryite

Classification

Strunz
10th ed.

9.CK

  • 9SilicatesClass
  • 9.CCyclosilicatesDivision
  • 9.CK[Si6O18]12- 6-membered single rings, with insular complex anionsGroup
  • 9.CKDarrellhenryiteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 2012Williams, P. A., Hatert, F., Pasero, M., Mills, S. J. (2012) New minerals and nomenclature modifications approved in 2012. CNMNC Newsletter No 14. Mineralogical Magazine, 76 (5) 1281-1288 doi:10.1180/minmag.2012.076.5.15DOI: 10.1180/minmag.2012.076.5.15
  2. 2013Novák, M., Ertl, A., Povondra, P., Galiová, M. V., Rossman, G. R., Pristacz, H., Prem, M., Giester, G., Gadas, P., Škoda, R. (2013) Darrellhenryite, Na(LiAl2)Al6(BO3)3Si6O18(OH)3O, a new mineral from the tourmaline supergroup. American Mineralogist, 98 (10) 1886-1892 doi:10.2138/am.2013.4416 DOI: 10.2138/am.2013.4416
  3. 2017(2017) Darrellhenryite. Handbook of Mineralogy. Mineralogical Society of America
