Cobaltarthurite

CoFe3+2(AsO4)2(OH)2 · 4H2O
IMA status
  • Approved
IMA symbol
Caru
IMA approved
2001
Also known as
  • Cobaltarthuriet
  • IMA2001-052
  • Kobaltarthurit

Where it forms, where it's found

Geological setting

Oxidation zone of a presumed prior sulfide deposit.

Type locality
La Reconquistada claim
  1. Pastrana
  2. Mazarrón
  3. Murcia
  4. Spain
4recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789103.5 – 4/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
vitreous to silky
Transparency
Translucent
Colour
Yellowish brown to straw yellow
Streak
White to pale brown
Tenacity
brittle
Cleavage
None Observed

none

Fracture
None observed
Density
3.22 g/cm³

Optical

Optical type
Biaxial (+)
Refractive index
1.741 – 1.797
Surface relief
High
Principal indices
nα 1.741 · nβ 1.762 · nγ 1.797
Pleochroism
Strong

X = almost colorless; Z = medium yellow.

Extinction
Parallel extinction and length slow. Z ≃ c.
Luminescence
none
UV response
Not fluorescent.
Notes

Absorption: Z > X, Y.

Michel-Lévy diagramhighlighted lineδ = 0.0560
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]560 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation560 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
#14
Cell parameters
a = 10.27 Å · b = 9.72 Å · c = 5.545 Å
Cell angles
β = 94.46 °
Ratio a:b:c
1 : 0.946 : 0.540
Unit cell volume
551.85 ų
Z
2
Type-locality form

Globular and pellet-like aggregates up to 1.5 mm in diameter, consisting of radial fibers and non-fibrous material.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1415.999223.986
40.39%
33AsArsenicArsenic274.922149.844
27.02%
26FeIronIron255.845111.690
20.14%
27CoCobaltCobalt158.93358.933
10.63%
1HHydrogenHydrogen101.00810.080
1.82%
Total554.533100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Cobaltarthuriet
  • IMA2001-052
  • Kobaltarthurit

In other languages

German
Cobaltarthurit · IMA 2001-052
Spanish
Cobaltarthurita
Italian
Cobaltarthurite · Cobaltoarthurite

Classification

Strunz
10th ed.

8.DC.15

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.DPhosphates, etc. with additional anions, with H2ODivision
  • 8.DCWith only medium-sized cations, (OH, etc.):RO4 = 1:1 and < 2:1Group
  • 8.DC.15CobaltarthuriteSpecies
Dana
8th ed.

42.11.20.05

  • 42Hydrated Phosphates, Etc.containing Hydroxyl or HalogenClass
  • 42.11(AB)3(XO4)2Zq·xH2OType
  • 42.11.20— unnamed intermediate level —Group
  • 42.11.20.05CobaltarthuriteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 2002Jambor, J. L., Vinals, J., Groat, L. A., Raudsepp, M. (2002) Cobaltarthurite, Co2+Fe3+2(AsO4)2(OH)2·4H2O, a new member of the arthurite group. The Canadian Mineralogist, 40 (2) 725-732 doi:10.2113/gscanmin.40.2.725 DOI: 10.2113/gscanmin.40.2.725
  2. 2002Raudsepp, M., Pani, E. (2002) The crystal structure of cobaltarthurite, Co2+Fe3+2(AsO4)2(OH)2·4H2O: a Rietveld refinement. The Canadian Mineralogist, 40 (2) 733-737 doi:10.2113/gscanmin.40.2.733 DOI: 10.2113/gscanmin.40.2.733
  3. 2005Kampf, A. R. (2005) The crystal structure of cobaltarthurite from the Bou Azzer District, Morocco: the location of hydrogen atoms in the arthurite structure-type. The Canadian Mineralogist, 43 (4) 1387-1391 doi:10.2113/gscanmin.43.4.1387 DOI: 10.2113/gscanmin.43.4.1387
  4. 2021(2021) Cobaltarthurite. Handbook of Mineralogy. Mineralogical Society of America
