Eosphorite

Mn2+Al(PO4)(OH)2 · H2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Eos
Discovered
1878
Also known as
  • Eosphoriet

Where it forms, where it's found

Geological setting

Granite Pegmatite

Secondary mineral in phosphate bearing granitic pegmatites.

Type locality
Fillow Quarry
  1. Branchville
  2. Redding
  3. Fairfield County
  4. Connecticut
  5. USA

41.2678°, -73.4392°

127recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous · Resinous
Transparency
Transparent · Translucent
Colour
Usually pale brown · golden brown · also medium brown to dark brown · occasionally pink · rose-red

Brown to black when oxidized

Streak
White
Tenacity
brittle
Cleavage
Poor/Indistinct

Poor on (100)

Fracture
Irregular/Uneven · Sub-Conchoidal
Density
3.06 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 45 – 50° · 2V calc = 54 – 66°
Refractive index
1.628 – 1.679
Surface relief
High
Principal indices
nα 1.628 – 1.644 · nβ 1.648 – 1.673 · nγ 1.657 – 1.679
Birefringence
0.032
Pleochroism
Visible

X= yellow Y= pink Z= pale pink to colorless

Dispersion
r < v strong
Extinction
Y^c = 4°-8°. XYZ = bac
UV response
Not fluorescent in UV
Michel-Lévy diagramhighlighted lineδ = 0.0320
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]320 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation320 nm
Order1st order
XPL colour

Crystallography

Crystal system
Orthorhombic
Space group
Cmca
Cell parameters
a = 6.928(1) Å · b = 10.445(1) Å · c = 13.501(2) Å
Ratio a:b:c
1 : 1.508 : 1.949
Z
8
Morphology

Crystals, commonly short to long prismatic, in planar radial or spherical radiating groups, with wedge-shaped terminations; globular, rarely massive.

Twinning

May exhibit twinning on (100) and (001), observable optically.

Comment

Originally thought to be monoclinic, twinned pseudo-orthorhombic.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen715.999111.993
48.92%
25MnManganeseManganese154.93854.938
24.00%
15PPhosphorusPhosphorus130.97430.974
13.53%
13AlAluminiumAluminium126.98226.982
11.79%
1HHydrogenHydrogen41.0084.032
1.76%
Total228.919100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Fe

Synonyms

  • Eosphoriet

In other languages

French
éosphorite
German
Eosphorit
Spanish
Eosforita
Italian
Eosforite
Japanese
エオスフォライト · エオスフォル石 · 曙光石

Classification

Strunz
10th ed.

8.DD.20

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.DPhosphates, etc. with additional anions, with H2ODivision
  • 8.DDWith only medium-sized cations, (OH, etc.):RO4= 2:1Group
  • 8.DD.20EosphoriteSpecies
Dana
8th ed.

42.07.01.02

  • 42Hydrated Phosphates, Etc.containing Hydroxyl or HalogenClass
  • 42.07(AB)2(XO4)Zq·xH2OType
  • 42.07.01Childrenite GroupGroup
  • 42.07.01.02EosphoriteSpecies
CIM

19.12.55

  • 19PhosphatesClass
  • 19.12Phosphates of MnGroup
  • 19.12.55EosphoriteSpecies

Group, growth & confusion

Often grow together
5 minerals
Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1878Brush, G.J., Dana, E.S. (1878) On a new and remarkable mineral locality in Fairfield County, Connecticut; with a description of several new species occurring there. First Paper. American Journal of Science and Arts: 16: 33-46; 114-123.
  2. 1913(1913) Atlas Der Krystallformen Vol. 2 - Text - Band II - Calaverit-Cyanochroit. Carl Winters Universitätsbuchhandlung, Heidelberg.
  3. 1914Slavík (1914) Bull. Ac. Sc. Bohême: 14, no. 4.
  4. 1921Larsen, Esper S. (1921) The microscopic determination of the nonopaque minerals. Bulletin 679. US Geological Survey doi:10.3133/b679 DOI: 10.3133/b679
  5. 1925Landes, Kenneth K. (1925) The paragenesis of the granite pegmatites of central Maine. American Mineralogist, 10 (11) 355-411
