Fluor-buergerite

NaFe3+3Al6(Si6O18)(BO3)3O3F
IMA status
  • Approved
IMA symbol
Fbu
Discovered
1966
Also known as
  • Fluor-buergeriet
  • IMA1965-005

Where it forms, where it's found

Type locality
Fluor-buergerite occurrence
  1. Mexquitic de Carmona Municipality
  2. San Luis Potosí
  3. Mexico

22.2667°, -101.1167°

3recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789107/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous to oily.
Transparency
Translucent
Colour
Bronze-brown to dark-brown.
Streak
Light brown.
Tenacity
brittle
Cleavage
Distinct/Good

on (1120)

Density
3.311 g/cm³

Optical

Optical type
Uniaxial (-)
Refractive index
1.655 – 1.735
Surface relief
High
Principal indices
nω 1.735 · nε 1.655
Birefringence
0.080
Extinction
Parrallel
Luminescence
Nonfluorescent.
UV response
Not known to fluoresce in UV
Michel-Lévy diagramhighlighted lineδ = 0.0800
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]800 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation800 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Trigonal
Space group
#86
Cell parameters
a = 15.8692 Å · c = 7.1882 Å
Z
3
Morphology

Columnar trigonal with pyramidal terminations

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen3015.999479.970
45.61%
14SiSiliconSilicon628.085168.510
16.01%
26FeIronIron355.845167.535
15.92%
13AlAluminiumAluminium626.982161.892
15.38%
5BBoronBoron310.81032.430
3.08%
11NaSodiumSodium122.99022.990
2.19%
9FFluorineFluorine118.99818.998
1.81%
Total1052.325100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Ti
  • Mn
  • Mg
  • Ca
  • K

Synonyms

  • Fluor-buergeriet
  • IMA1965-005

In other languages

German
Fluor-Buergerit · IMA1965-005
Spanish
Buergerita
Italian
Buergerite · Fluor-buergerite
Portuguese
Buergerita · Buergerite · IMA1965-005
Chinese
钠铁电气石

Classification

Strunz
10th ed.

9.CK.05

  • 9SilicatesClass
  • 9.CCyclosilicatesDivision
  • 9.CK[Si6O18]12- 6-membered single rings, with insular complex anionsGroup
  • 9.CK.05Fluor-buergeriteSpecies
Dana
8th ed.

61.03.01.05

  • 61Cyclosilicates Six-membered RingsClass
  • 61.03Six-Membered Rings with borate groupsType
  • 61.03.01— unnamed intermediate level —Group
  • 61.03.01.05Fluor-buergeriteSpecies
CIM

17.5.45

  • 17Silicates Containing other AnionsClass
  • 17.5BorosilicatesGroup
  • 17.5.45Fluor-buergeriteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 1966Donnay, Gabrielle; Ingamells, C. O.; Mason, Brian (1966) Buergerite, a new species of tourmaline. American Mineralogist, 51 (1-2). 198-199
  2. 1969Barton Jnr, R. (1969) Refinement of the crystal structure of buergerite and the absolute orientation of tourmalines. Acta Crystallographica Section B Structural Crystallography and Crystal Chemistry, 25 (8) 1524-1533 doi:10.1107/s0567740869004286DOI: 10.1107/s0567740869004286
  3. 1971Tippe, Armin, Hamilton, Walter C. (1971) A neutron diffraction study of the ferric tourmaline buergerite. American Mineralogist, 56 (1-2) 101-113
  4. 1996Grew, Edward S.; Anovitz, Lawrence M. - Eds. (1996) Boron - Mineralogy, Petrology and Geochemistry. Reviews in Mineralogy Vol. 33. Mineralogical Society of America p.862
  5. 2011Henry, Darell J., Novak, Milan, Hawthorne, Frank C., Ertl, Andreas, Dutrow, Barbara L., Uher, Pavel, Pezzotta, Federico (2011) Nomenclature of the tourmaline-supergroup minerals. American Mineralogist, 96 (5) 895-913 doi:10.2138/am.2011.3636 DOI: 10.2138/am.2011.3636
