Fluor-elbaite

Na(Li1.5Al1.5)Al6(Si6O18)(BO3)3(OH)3F
IMA status
  • Approved
IMA symbol
Felb
IMA approved
2011
Also known as
  • Fluor-elbaiet
  • IMA2011-071
  • UM2000-//-SiO:AlBFLiNa
  • +1 more

Where it forms, where it's found

Geological setting

Granitic pegmatite.

Type locality
Cruzeiro mine
  1. São José da Safira
  2. Minas Gerais
  3. Brazil

-18.2710°, -42.1828°

42recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789107.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Colour
Green · blue-green · blue · red to pink · orange · yellow · colourless

The blue-green bulk color (and pleochroism) is thought to be caused by minor concentrations of chromophores (e.g., Fe and Mn). Pure, end-member fluor-elbaite is colorless.

Streak
White
Tenacity
brittle
Fracture
Sub-Conchoidal
Density
3.107 g/cm³

Optical

Optical type
Uniaxial (-)
Refractive index
1.625 – 1.64
Surface relief
Moderate
Principal indices
nω 1.640 · nε 1.625
Pleochroism
Visible

O = green/bluish green, E = pale green

Michel-Lévy diagramhighlighted lineδ = 0.0150
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]150 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation150 nm
Order1st order
XPL colour

Crystallography

Crystal system
Trigonal
Space group
#86
Cell parameters
a = 15.8933(2) Å · c = 7.1222(1) Å
Unit cell volume
1558.02 ų
Z
3
Type-locality form

Euhedral, blue-green elongated prisms to < 1.5 x 2.5 cm.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen3015.999479.970
51.13%
13AlAluminiumAluminium7.526.982202.365
21.56%
14SiSiliconSilicon628.085168.510
17.95%
5BBoronBoron310.81032.430
3.46%
11NaSodiumSodium122.99022.990
2.45%
9FFluorineFluorine118.99818.998
2.02%
3LiLithiumLithium1.56.94010.410
1.11%
1HHydrogenHydrogen31.0083.024
0.32%
Total938.697100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Fluor-elbaiet
  • IMA2011-071
  • UM2000-//-SiO:AlBFLiNa
  • Unnamed (F-analogue of Elbaite)

In other languages

German
Fluor-Elbait · IMA 2011-071
Italian
fluor-elbaite

Classification

Strunz
10th ed.

9.CK.05

  • 9SilicatesClass
  • 9.CCyclosilicatesDivision
  • 9.CK[Si6O18]12- 6-membered single rings, with insular complex anionsGroup
  • 9.CK.05Fluor-elbaiteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 1999Hawthorne, Frank C., Henrys, Darrell J. (1999) Classification of the minerals of the tourmaline group. European Journal of Mineralogy, 11 (2) 201-216 doi:10.1127/ejm/11/2/0201DOI: 10.1127/ejm/11/2/0201
  2. 2001Akizuki, Mizuhiko, Kuribayashi, Takahiro, Nagase, Toshiro, Kitakaze, Arashi (2001) Triclinic liddicoatite and elbaite in growth sectors of tourmaline from Madagascar. American Mineralogist, 86 (3) 364-369 doi:10.2138/am-2001-2-320DOI: 10.2138/am-2001-2-320
  3. 2005Rozhdestvenskaya, I. V., Frank-Kamenetskaya, O. V., Zolotarev, A. A., Bronzova, Yu. M., Bannova, I. I. (2005) Refinement of the crystal structures of three fluorine-bearing elbaites. Crystallography Reports, 50 (6) 907-913 doi:10.1134/1.2132394DOI: 10.1134/1.2132394
  4. 2009Ertl, Andreas, Kolitsch, Uwe, Meyer, Hans-Peter, Ludwig, Thomas, Lengauer, Christian L., Nasdala, Lutz, Tillmanns, Ekkehart (2009) Substitution mechanism in tourmalines of the "fluor-elbaite"-rossmanite series from Wolkenburg, Saxony, Germany. Neues Jahrbuch für Mineralogie - Abhandlungen, 186 (1) 51-61 doi:10.1127/0077-7757/2009/0136DOI: 10.1127/0077-7757/2009/0136
  5. 2009Natkaniec-Nowak, Lucyna, Dumańska-Słowik, Magdalena, Ertl, Andreas (2009) “Watermelon” tourmaline from the Paprok mine (Nuristan, Afghanistan) Neues Jahrbuch für Mineralogie - Abhandlungen, 186 (2) 185-193 doi:10.1127/0077-7757/2009/0145DOI: 10.1127/0077-7757/2009/0145
