Graulichite-(La)

LaFe3+3(AsO4)2(OH)6
IMA status
  • Approved
IMA symbol
Grl-La
IMA approved
2021
Also known as
  • Graulichiet-(La)
  • IMA2020-093

Where it forms, where it's found

Geological setting

Oxidation zone of a Cu deposit; the REEs most likely derived from the local igneous rocks; the association includes a yet unspecified synchysite-like REE carbonate.

Type locality
Bou Skour Mine
  1. Bou Skour mining district
  2. Agdz Cercle
  3. Zagora Province
  4. Drâa-Tafilalet Region
  5. Morocco

30.9297°, -6.3014°

2recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789103.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Yellow
Streak
Pale yellow
Tenacity
brittle
Cleavage
None Observed
Fracture
Irregular/Uneven
Density
3.935 g/cm³

Optical

Birefringence
Difficult to observe because interference colors are masked by the yellow color of the mineral.
Pleochroism
Weak

Very weak, light yellow to yellow.

Notes

Mean refractive index, calculated according to the Gladstone-Dale relationship is 1.889 to 1.928.

Crystallography

Crystal system
Trigonal
Space group
R-3m
Cell parameters
a = 7.252(13) Å · c = 16.77(3) Å
Morphology

Rhombohedral crystals.

Parting
None observed.
Type-locality form

Rhombohedral crystals, up to 0.1 mm in size.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1415.999223.986
32.64%
26FeIronIron355.845167.535
24.41%
33AsArsenicArsenic274.922149.844
21.83%
57LaLanthanumLanthanum1138.905138.905
20.24%
1HHydrogenHydrogen61.0086.048
0.88%
Total686.318100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Graulichiet-(La)
  • IMA2020-093

In other languages

German
Graulichit-(La) · IMA 2020-093

Classification

Strunz
10th ed.

8.BL

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.BPhosphates, etc., with additional anions, without H2ODivision
  • 8.BLWith medium-sized and large cations, (OH, etc.):RO4 = 3:1Group
  • 8.BLGraulichite-(La)Species

Group, growth & confusion

Literature, links & citation

Citations
  1. 2021Miyawaki, Ritsuro, Hatert, Frédéric, Pasero, Marco, Mills, Stuart J. (2021) IMA Commission on New Minerals, Nomenclature and Classification (CNMNC) CNMNC Newsletter No 60. Mineralogical Magazine, 1-5 doi:10.1180/mgm.2021.30DOI: 10.1180/mgm.2021.30
  2. 2022(2022) Graulichite-(La). Handbook of Mineralogy. Mineralogical Society of America
  3. 2022Biagioni, Cristian, Ciriotti, Marco E., Favreau, Georges, Mauro, Daniela, Zaccarini, Federica (2022) Graulichite-(La), LaFe3+3(AsO4)2(OH)6, a new addition to the alunite supergroup from the Patte d'Oie mine, Bou Skour mining district, Morocco. European Journal of Mineralogy, 34 (3) 365-374 doi:10.5194/ejm-34-365-2022 DOI: 10.5194/ejm-34-365-2022
